Flexem FR-T0400K Temperature Acquisition Module
Discover the Flexem FR-T0400K temperature monitoring solution. This versatile module supports multiple sensor types and applications. It delivers accurate temperature measurements for industrial processes. Powergear X Automation brings you reliable measurement technology. Need help? Contact sales@powergearx.com or +86 18030005825.
Measurement Capabilities
- 4 independent temperature channels
- Supports 9 thermocouple types: K, J, R, S, B, E, T, N, C
- Compatible with NTC thermistors
- Wide temperature ranges for different sensors
- High accuracy across all measurement ranges
Technical Performance
- Brand: Flexem | Model: FR-T0400K
- Measurement accuracy: ±0.5% or ±1°C
- Thermocouple accuracy: ±0.3% or ±1°C
- NTC accuracy: ±0.1% or ±1°C
- Power consumption: 50mA maximum at 5V DC
- Compact dimensions: 111×18×76 mm
- Lightweight design: only 65 grams
- Sampling rate: 10 samples per second
- Input impedance: 1MΩ minimum
- Isolation voltage: 500V AC
Temperature Ranges
- PT700: -200 to 850°C
- PT1000: -200 to 600°C
- Cu50: -50 to 150°C
- NI100: -60 to 180°C
- Cu100: -50 to 150°C
- NI1000: -60 to 180°C
Installation & Support
- Easy DIN rail mounting
- 12-month product warranty
- Global shipping: FedEx, UPS, DHL
- Operating temperature: -20 to 70°C
- Storage temperature: -40 to 85°C
- Humidity range: 5% to 95% non-condensing
Expert Questions & Answers
- Which sensors work best for high temperatures?
- Type R, S, and B thermocouples handle highest temperatures.
- How do I calibrate the module?
- Use known temperature sources and adjustment software.
- Can I mix different sensor types?
- Yes, each channel independently configures sensor type.
- What wiring distance is recommended?
- Keep sensor wires under 30 meters for best accuracy.
- How to handle noisy environments?
- Use shielded cables and proper grounding techniques.
