Flexem FC5-20MR-AC Programmable Logic Controller with Ethernet

Flexem FC5-20MR-AC Programmable Logic Controller

The FC5-20MR-AC delivers reliable industrial automation control. This PLC works with AC220V power supply. It offers twelve input points and eight relay outputs. Powergear X Automation designed it for easy expansion. The unit includes multiple communication options.

Detailed Specifications

• Brand: Flexem | Model: FC5-20MR-AC | Type: Programmable Logic Controller
• Power Supply: AC220V with ±15% tolerance range
• Input Points: 12 points digital input
• Output Points: 8 points relay output
• Relay Contact Capacity: 2A at 250V AC resistive load
• Expansion Capacity: Maximum 31 I/O modules supported
• Expansion Boards: 1 board can be added directly
• Ethernet Port: 1×RJ45, 10/100M self-adaptive
• Serial Ports: 2 channels (RS232/RS485 configurable)
• Baud Rate: 4800-115200bps adjustable
• Program Memory: 16KB for application logic
• Data Memory: 8KB for variable storage
• Operating Temperature: -10°C to 55°C
• Storage Temperature: -25°C to 70°C
• Humidity Range: 5-95% RH non-condensing
• Installation: Standard 35mm DIN rail mounting
• Weight: Approximately 400 grams

Communication Interfaces

• Ethernet port supports Modbus TCP protocol
• Serial ports support Modbus RTU communication
• USB Type-C for programming and monitoring
• DB9 connector for serial device connection
• Terminal block for wiring convenience

Expansion Capabilities

• Connect up to 31 additional I/O modules
• Single expansion board slot available
• Compatible with Flexem expansion series
• Flexible system configuration options

Model Number Breakdown

• FC5: Basic logic control series
• 20: Total I/O points (12 input + 8 output)
• MR: Relay output type
• AC: AC220V power supply type

Installation Instructions

• Mount on standard 35mm DIN rail securely
• Connect AC220V power within specified range
• Use proper wire gauges for all connections
• Ensure adequate clearance for ventilation
• Follow local electrical safety standards

Package Contents

• 1 x Flexem FC5-20MR-AC main unit
• 1 x User manual and programming guide
• 1 x DIN rail mounting clip set
• All necessary installation accessories
• Shipping via FedEx, UPS, or DHL available
• 12-month manufacturer warranty included

Expert Questions & Answers

• What power supply does this PLC require?
• It operates on standard AC220V power source.
• How many expansion modules can I add?
• You can connect up to 31 additional I/O modules.
• What communication protocols are supported?
• It supports Modbus TCP, Modbus RTU, and proprietary protocols.
• Can I use this for motor control applications?
• Yes, the relay outputs can control small motors directly.
• What programming software works with this unit?
• Use Flexem programming software for configuration.
