F5-MD0008P Flexem Digital Output Module 8 Channels 0.5A 24VDC PLC Expansion

Product Overview

• Flexem F5-MD0008P – a compact digital output module from the FC5 series. It runs on 24VDC and offers 8 transistor outputs (NPN or PNP type) for controlling actuators.
• Designed for industrial automation. Provides reliable switching for relays, indicators, solenoids, and small motors.
• Features short circuit protection with auto-recovery, fast switching (34μs ON, 250μs OFF), and optical isolation. Simple to install and configure.

Model & Ordering Tree (Hierarchical Suffix)

• F5 (FC5 Series Digital Module)
  • -MD (Digital Module)
    • 0008P (0 Inputs, 8 Outputs, PNP/NPN Transistor)
      • 24VDC (Power Supply)
• Full model: F5-MD0008P – 8 digital outputs, 24VDC, IP20, FC5 series expansion module.

Core Technical Data

• Power supply: 24VDC (19.2‑28.8V range).
• Outputs: 8 digital outputs, transistor type (NPN or PNP – specify when ordering).
• Rated current: 0.5A per point, 0.5A per common group.
• Voltage drop: maximum 1VDC at rated current.
• Leakage current (OFF): <5μA.
• Switching speed: ON <34μs, OFF <250μs.
• Maximum output frequency: 1kHz.
• Protection: short circuit protection, self-recovery every 10ms.
• Peak short-circuit current: 1.3A.
• Clamping voltage: 39V±1V for inductive loads.
• Isolation: 500V AC between output and internal logic.
• Cable: unshielded up to 50m.
• Wiring: removable terminal block.
• Dimension: Dimension A (standard FC5 module size).

Environmental & Immunity

• Operating temperature: -10°C to 60°C.
• Protection: IP20 (finger safe).
• Compliance: RoHS, REACH. Meets industrial standards.

Quick Installation Guide

• Mount on 35mm DIN rail next to FC5 series CPU.
• Connect 24VDC power to module terminals.
• Wire loads to output terminals 0‑7 (observe polarity for your output type).
• Module automatically detected by CPU – no complex setup.
• Removable terminal blocks for easy wiring.

Diagnostics & Maintenance

• LED indicators: power and output status per point.
• Monitor output status via PLC programming software.
• Short circuit protection auto-recovery – no manual reset needed.
• No routine calibration required. Keep clean and dry.

Compatibility & Certifications

• Fully compatible with all FC5 series PLCs (FC5, FC5M).
• Works with FC5 expansion backplane and power supply.
• Certified: RoHS compliant, REACH unaffected.

Package & Warranty

• Includes: F5-MD0008P module, mating connector, quick guide.
• Warranty: 12 months against defects. Extended options available.

Professional FAQ (Experience-based & Selection Guide)

• Is this module NPN or PNP output?
  The F5-MD0008P supports both types – please specify your requirement when ordering. NPN sinks current, PNP sources current.
• Can I use this module to drive small motors or solenoids?
  Yes, up to 0.5A per point. For inductive loads, the built-in clamping diode protects the output. For higher current, use an external relay.
• What happens if an output shorts?
  The module detects short circuit and protects the output. It attempts self-recovery every 10ms. Once the short is removed, output resumes normal operation.
• Which shipping carriers do you use for international orders?
  We ship worldwide via FedEx, UPS, DHL. All services include tracking. Contact us for bulk discounts.
• How do I choose between F5-MD0008P and MD0016P (16 outputs)?
  Choose MD0008P if you need 8 outputs. Choose MD0016P if you need 16 outputs in one module to save space. Both have same 0.5A per point rating.

Typical Applications

• Expand output capacity of FC5 PLC systems.
• Control relays, indicators, and buzzers.
• Drive small DC solenoids and valves.
• Interface with motor contactors (via external relay).
• Educational PLC training systems.
