Emerson EZ1080 8mm Eddy Current Sensor Introduction
The EZ1080-05-00-015 eddy current sensor delivers precise non-contact measurement for turbomachinery. This robust sensor monitors shaft displacement and position in demanding environments. Engineers trust its reliability in turbines, compressors, and gearboxes. Powergear X designs this sensor for long-term industrial performance.
Technical Specifications
- Brand: Emerson | Model: EZ1080-05-00-015
- Linear Measurement Range: 2 mm (80 mils)
- Initial Air Gap: 0.5 mm (20 mils) for optimal performance
- Incremental Scale Factor: 7.87 V/mm or 8 V/mm ±5%
- Deviation from Straight Line: ±0.025 mm across 0-45°C
- Minimum Target Size: 14mm diameter | Shaft: 20mm diameter
- Target Materials: AISI/SAE 4140, 1035, 4340, and other steels
- Protection Class: IP67/IP68 with 10000 hpa pressure rating
- Operating Temperature: -35°C to +180°C (sensor with 1m cable)
- Connector: M10x1 thread with 0mm unthreaded section
- Cable: 1.5 meters FEP with nickel-plated brass connector
Environmental and Safety Compliance
- ATEX, IEC-Ex, CSA, and CCC certifications for hazardous areas
- Marine DNV GL approval for ships and offshore units
- SIL 2 Capable per IEC 61508:2010 safety standard
- CE marked for EU electromagnetic compatibility
- Temperature Classification: T2, T4, T6 for various ambient ranges
Ordering Information and Model Suffix
- EZ1080: 8mm Eddy Current Sensor Series
- -05-: 50mm sleeve length for flexible mounting
- 00: 0mm unthreaded length for direct installation
- 015: 1.5 meter cable length for connectivity
- Case Thread: M10x1 metric thread standard
- Armored Cable: Not included in this configuration
Installation Guidelines
- Maintain initial air gap of 0.5mm between sensor and target
- Ensure target material meets specified ferromagnetic steel types
- Use recommended minimum shaft diameter of 25mm for accuracy
- Verify differential pressure limits up to 120°C operation
- Check all connections for IP67/68 sealing integrity
Packaging Contents
- One EZ1080-05-00-015 eddy current sensor
- Pre-attached 1.5 meter FEP industrial cable
- M10x1 threaded connector for secure mounting
- Documentation sheet with calibration data
Shipping and Delivery
- Global express shipping via FedEx, UPS, or DHL
- Standard lead time of 5-7 business days
- Customs and duty support for international orders
- Real-time tracking provided after dispatch
Frequently Asked Questions
- What is the typical lifespan of this sensor?
- The sensor lasts over 10000 hours in continuous operation at 120°C
- Can I use this sensor underwater or in oil submersion?
- Yes, the IP68 rating protects against water and oil ingress
- What converters work with the EZ1080 series?
- Compatible with most eddy current converters from major brands
- How do I confirm the sensor gap during installation?
- Use a feeler gauge to set the 0.5mm initial air gap precisely
- Does the price include calibration certificate?
- No, DOC-TEST certificate requires separate ordering
Contact Our Engineering Team
- Email: sales@powergearx.com
- Phone: +86 18030005825 (WhatsApp)
- We provide custom sizing and application support
- Request same-day quotations for volume orders
