EVF8202-E Variable Frequency Drive — Lenze 1 HP VFD

Lenze EVF8202-E Variable Frequency Drive

Quick Product Summary

• Lenze EVF8202-E converts single-phase 230 VAC input to three-phase output.
• Output voltage: 0–230 VAC three-phase.
• Output frequency: 0–480 Hz for wide motor control.
• Power rating: 0.75 kW (1 HP). Model: EVF8202-E.
• Compact and light. Weight: 1.62 kg.
• Author: Powergear X Automation.

Core Technical Data

• Manufacturer: Omron
• Part Number: EVF8202-E
• Input: 1-phase, 230 VAC, 50/60 Hz, 9 A
• Output: 3-phase, 0–230 VAC, up to 4 A
• Frequency Range: 0–480 Hz
• Rated Power: 0.75 kW (1 HP)
• Ambient Temp: 0 to 50 °C
• Mounting: Panel or chassis mount
• Weight: 1.62 kg

Extended Specs and Added Values

• Efficiency: high conversion efficiency above 95% in typical load.
• Overload Capacity: 150% rated current for 60 seconds.
• Switching Frequency: selectable up to 8 kHz for quiet motors.
• Harmonic Distortion: low at nominal load with built-in smoothing.
• Protection Rating: IP20 (panel-mounted installations).
• Cooling: forced air through built-in fan.
• Control I/O: basic digital and analog inputs for start/stop and speed set.
• Safety features: overcurrent, short-circuit, and over-temperature trips.
• EMC: meets industrial EMI limits with correct grounding.

Key Selling Points

• Simple install. Fits common control panels.
• Wide frequency span for precise speed control.
• Small size saves panel space.
• Good for pumps, fans, conveyors, and small compressors.
• Stable output reduces motor wear.
• Offers soft start to cut mechanical stress.

Installation Notes

• Mount on a flat panel with ventilation space.
• Use the correct fusing on input lines.
• Keep power and control cables separate.
• Ground the unit well for EMC control.

Commissioning & Maintenance

• Set motor parameters before first run.
• Test at low speed first.
• Check cooling fan monthly.
• Clean dust from vents regularly.

Shipping & Warranty

• Shipping options: FedEx, UPS, DHL.
• All units ship in protective packing.
• Warranty: 12 months from invoice date.

Compatibility & Applications

• Works with standard three-phase motors up to 1 HP.
• Ideal for conveyors, pumps, fans, and mixers.
• Use with encoder feedback for closed-loop control if needed.

Professional FAQ

• What motor sizes work best with this drive?
• Small motors up to 1 HP run best. Check starting torque needs.
• Do I need to derate the drive at high altitude?
• Yes. At altitude above 1000 m, reduce rating per motor and ventilation guidance.
• Can I fit a braking resistor to the unit?
• Some models allow external braking. Confirm resistor specs with us.
• How to improve EMC in noisy plants?
• Use shielded cables and separate power routing. Add an external filter if needed.
• How to program custom speed ramps?
• Use the onboard keypad or a simple PLC. Save common profiles to the drive.

How to Order

• Contact sales at sales@powergearx.com
• Call or WhatsApp: +86 18030005825
• Include part number EVF8202-E and quantity in your request.

Contact Information Inquiries: sales@powergearx.com | +86 18030005825
