Product details
Omron ESMD222L4TXA Motor Controller – 2.2 kW (3 HP)
This Omron motor controller delivers reliable performance for industrial applications. With 2.2 kW (3 HP) power rating, it handles various motion control tasks. It features multiple communication options and constant torque operation.
Key Features & Benefits
- Powerful Performance: 2.2 kW (approximately 3 HP) output for demanding applications.
- Dual Communication: Supports RS485 (Modbus RTU) and CAN-BUS protocols.
- Industrial Standard: Three-phase 400V supply voltage for factory environments.
- Precise Control: Built-in PI controller for accurate regulation.
- Compact Design: Open-frame IP20 enclosure for panel mounting.
- Wide Temperature Range: Operates from 0°C to +55°C.
- Constant Torque: Suitable for general-purpose applications requiring steady torque.
Technical Specifications
Basic Information
- Manufacturer: Lenze
- Part Number: ESMD222L4TXA
- Product Line: Other
- Product Type: Motor Controller
- Power Rating: 2.2 kW (Approx. 3 HP)
- Rated Current: 5.3 A
- Author: Powergear X Automation
Electrical Characteristics
- Supply Voltage: Three Phase 400V
- Input Phase: 3 Phase
- Performance Level: Basic
- Controller Type: PI-controller (PID)
- Torque Type: Constant Torque (General Purpose)
- Communication: RS485 (Modbus RTU), CAN-BUS
Physical & Environmental
- Enclosure Protection: IP20 (open-frame, for control panels)
- Filter Requirement: Required as a separate unit
- Operating Temperature: 0°C to +55°C
- Storage Temperature: -20°C to +70°C
- Mounting: Designed for panel installation
Typical Applications
- Conveyor system speed control
- Pump and fan motor regulation
- Packaging machine drives
- Material handling equipment
- Industrial automation systems
- Production line machinery
Warranty & Shipping Information
This product comes with a full 12-month warranty. We ship worldwide using FedEx, UPS, and DHL express services. Tracking details are provided within 24 hours of shipment confirmation.
Professional FAQ
Q: What type of filter is required for this controller?
A: An external EMC filter is required to reduce electromagnetic interference. The specific filter model depends on your installation requirements and local regulations.
Q: Can this controller be used with single-phase motors?
A: No, it is designed for three-phase motors only. The supply voltage is three-phase 400V, and it requires a three-phase motor connection.
Q: How do I connect this controller to a PLC system?
A>You can use either the RS485 (Modbus RTU) or CAN-BUS communication ports. Connect the appropriate cables and configure the communication parameters in both the controller and your PLC.
Q: What’s the difference between PI and PID control?
A>This controller has a PI (Proportional-Integral) controller, which handles most applications well. PID adds Derivative control for systems needing faster response to sudden changes.
Q: Can I use this controller in outdoor applications?
A>No, the IP20 rating means it’s only for indoor use in control panels. It provides basic protection against solid objects but no protection against water or dust.
