Enveloping Trendmaster Pro Accelerometer 200157-08-05

Bently Nevada 200157-08-05 Enveloping Trendmaster Pro Accelerometer

Product Overview

The Bently Nevada 200157-08-05 is an enveloping accelerometer designed for critical machine monitoring. It works with Trendmaster Pro systems and supports acceleration-to-velocity with enveloping signal processing. It is best for roller bearings and cavitation detection.

Electrical Specifications

• Sensitivity: 10.2 mV/(m/s²)
• Measurement Range: ±245 m/s² (±25 g)
• Bias Voltage: +2.5 Vdc ± 0.23 V
• Input Voltage: 4.7 to 5.5 Vdc
• Current: Less than 800 µA
• Frequency Range: 10 to 10,000 Hz
• Resonance: >20 kHz
• Linearity: ±2% (1 to 10 g peak)
• Transverse Sensitivity: ≤7%

Model Suffix Tree

• 200157 = Enveloping Accelerometer Series
• 08 = 1/2 NPT, 1 inch hex mounting stud
• 05 = Multi-certification approved

Installation Instructions

• Install using included 1 inch hex stud
• Tighten with torque: 2.7 to 6.8 N·m
• Let adhesive mount cure for 24 hours

Package Includes

• 1 × 200157-08-05 Accelerometer
• 1 × Mounting Stud
• Basic User Guide
• 12-Month Warranty (certificate not included)
