Product details
Emerson EZ1080 Eddy Current Sensor – Premium Performance
The EZ1080 series delivers exceptional accuracy for industrial monitoring. This 8mm sensor measures shaft displacement without contact.
Key Advantages
- Non-contact measurement prevents wear
- Wide temperature range from -35°C to +180°C
- IP67/IP68 protection for harsh environments
- Global certifications for hazardous areas
- Easy installation with M10x1 threads
Technical Excellence
- Measurement Range: 2.0 mm linear
- Initial Gap: 0.5 mm recommended
- Sensitivity: 7.87 V/mm or 8 V/mm options
- Accuracy: ±0.025 mm deviation
- Response: 0 to 10 kHz frequency
- Target Size: 14mm minimum, 20mm ideal
Robust Construction
- Sensor Tip: Glass-fiber reinforced PEEK
- Case Material: Stainless steel
- Cable: FEP with nickel-plated connector
- Weight: Only 100 grams with cable
- Pressure Rating: 10000 hPa at 120°C
Model Breakdown
- EZ1080: 8mm Eddy Current Sensor Series
- -18-: 180mm case length for deep mounting
- -08-: 80mm unthreaded installation section
- -010: 1.0 meter standard cable length
Installation Guide
- Mount with M10x1 threads securely
- Maintain 0.5mm initial air gap
- Use 20mm minimum target size
- Ensure proper grounding
- Verify all connections are tight
Package Contents
- 1 x EZ1080-18-08-010 Sensor Unit
- 1 x 1-meter high-temperature cable
- 1 x Installation manual
- 1 x 12-month warranty certificate
Shipping Services
- Fast worldwide delivery available
- FedEx Express for urgent orders
- UPS Ground for standard shipping
- DHL International for global reach
- Real-time tracking provided
Expert FAQ
- What is the maximum cable length for EZ1080?
You can extend up to 10 meters with proper signal conditioning.
- Can this sensor measure non-ferrous materials?
No, it requires ferromagnetic steels like AISI 4140 for best results.
- What is the sensor’s temperature classification?
It carries T4, T6, and T2 classifications for different temperature ranges.
- How often does the sensor need calibration?
Annual calibration is recommended for critical applications.
- Is the pressure seal tested before shipment?
Pressure testing requires separate DOC-TEST certificate ordering.
