ControlLogix 1756-L63 | Allen-Bradley with 8MB Memory

Allen-Bradley 1756-L63 ControlLogix Processor | High-Power 1756-L63 PAC for Industrial Automation

Full technical details: Download Installation Manual

Technical Specifications

• Brand: Allen-Bradley | Model: 1756-L63
• Series: ControlLogix Logix5563
• Memory: 8MB user + 478KB I/O dedicated
• I/O Capacity: 128,000 digital / 4,000 analog points
• Speed: 0.08ms program scan time
• Power Use: 1.2A @5V DC, 14mA @24V DC
• Heat Output: 11.9 BTU/hour
• Temp Range: 0°C to 60°C operating
• Shock Resistance: 30g operating / 50g non-operating
• Weight: 0.71 lbs (0.32 kg)

Advanced Features

• Full redundancy support for critical systems
• USB port for quick programming access
• CompactFlash support (up to 128MB)
• Motion control over EtherNet/IP
• Battery backup for memory protection

Compatibility & Networks

• Chassis: 1756-A4, A7, A10, A13, A17
• Power Supplies: PA50, PB72, PB75R and others
• Networks: EtherNet/IP, ControlNet, DeviceNet
• Protocols: Modbus, DF1, DH-485, ASCII
• Safety: Works with GuardLogix systems

Reliability & Support

• 12-month warranty
• Global shipping: FedEx, UPS, DHL
• Humidity tolerance: 5-95% non-condensing
• Vibration resistance: 2g @10-500Hz
• 720V DC isolation tested

Expert Questions

• Q: What battery does it use?
  A: 1756-BA1, BATM, BA2 or BATA
• Q: Maximum analog points?
  A: 4,000 analog I/O signals
• Q: Supports motion control?
  A: Yes via SERCOS or EtherNet/IP
• Q: Non-volatile memory options?
  A: 128MB CompactFlash (1784-CF128)
• Q: Redundancy capability?
  A: Full controller redundancy support
