Allen-Bradley 1769-OV32T CompactLogix 32-Point Sinking Output Module
The Allen-Bradley 1769-OV32T is a high-density 32-point DC sinking output module. It offers solid-state performance for industrial automation applications. This module is part of the versatile CompactLogix family from Rockwell Automation.
🔧 Key Technical Specifications
- Brand: Allen-Bradley / Rockwell Automation
- Model: 1769-OV32T (Series A and B)
- Module Type: 32-Point Digital Output
- Output Type: Sinking, Solid-state
- Voltage Rating: 24V DC (10.2–26.4V DC operating range)
- Wire Type: Copper, 90°C rated
- Solid Wire Size: 14–22 AWG
- Stranded Wire Size: 16–22 AWG
- Enclosure: Open style (requires protective installation)
- Mounting: Panel or DIN rail with interlocking connectors
- Shipping Weight: 2 lbs (450 g)
- Dimensions: 8 × 8 × 5 inches (118 × 35 × 87 mm)
⚡ Installation Guidelines
- Use only 90°C rated copper wire for all connections
- Compatible with 14-22 AWG solid or 16-22 AWG stranded wire
- Mount securely using tongue-and-groove connectors
- Protect from debris, static electricity, and UV exposure
- Ensure proper ventilation around the module during operation
🖥️ System Compatibility
- CompactLogix Controllers
- MicroLogix 1500 Controllers
- 1769-ADN DeviceNet Adapters
- 1769-AENTR Ethernet/IP Adapters
- All 1769 Series I/O modules
📦 Packaging Information
- One Allen-Bradley 1769-OV32T module
- Shipping via FedEx, UPS, or DHL
- Package weight: 2 lbs (450 g)
- Package dimensions: 8 × 8 × 5 inches
❓ Frequently Asked Questions
- What controllers work with this module?
It connects to CompactLogix, MicroLogix 1500, and 1769 adapters. - What wire size should I use?
Use 14-22 AWG solid or 16-22 AWG stranded copper wire. - Is the module protected against environmental factors?
No, the open enclosure requires installation in a protected area. - How many points does this module have?
It provides 32 sinking output points in groups of 16.
