Siemens 6ES7138-4CB10-0AB0 | SIMATIC DP PM-E Power Module for ET200S

Model: 6ES7138-4CB10-0AB0
Brand: Siemens
Warranty: 12 Months Factory Warranty
Delivery: FedEx · UPS · DHL
Inquiries: sales@powergearx.com |
WhatsApp +86 18030005825

• Reliable SIMATIC DP PM-E Power Module for ET200S systems
• Supports DC 24–56.7V and AC 24–230V load voltage
• Includes reverse polarity and short-circuit protection
• Integrated diagnostic LEDs (SF, PWR, FSG)
• Universal parameter configuration for AC/DC loads
• Compact design: 15×81×52 mm, weight 34 g
• Replaceable fuse for added protection (5×20 mm)

Main Technical Data

• Rated Load Voltage: 24–56.7 VDC / 24–48–120–230 VAC
• Isolation Voltage: 1500 VDC tested
• Power Loss (typical): 5 W
• Max Current Capacity: up to 10 A (DC) / up to 8 A (AC)
• Current Consumption (Bus): max. 9.5 mA
• Overvoltage Protection: Yes
• Operating Temperature: -25 °C to +60 °C
• Fuse Type: IEC 127-2/1, 250 V, 10 A fast fuse
• Diagnostic Functions: Group error, voltage monitoring, backup LED

Suffix Code Tree

• 6ES7138-4CB10-0AB0
  • Series: ET200S
  • Module Type: PM-E Power Module
  • Voltage Range: DC 24–56.7V / AC 24–230V
  • Isolation: 1500 VDC
  • Fuse: Replaceable (5×20 mm)

Product Advantages

• Easy setup for ET200S distributed I/O systems
• Monitors voltage groups efficiently
• Works with both DC and AC loads
• Diagnostic LEDs provide real-time feedback
• Compact and lightweight for space-saving installations

Shipping & Warranty

• Fast global shipping via FedEx / UPS / DHL
• Brand new and factory sealed
• 12-Month Warranty on all Siemens modules

FAQ

• Q1. What is the main purpose of this Siemens 6ES7138-4CB10-0AB0 power module?
  It provides stable power and monitoring for ET200S electronic modules, ensuring reliable communication and system safety.
• Q2. Can this module handle both AC and DC loads?
  Yes. It supports 24–56.7 VDC and 24–230 VAC configurations for flexible use.
• Q3. How often should the fuse be checked or replaced?
  Inspect the 5×20 mm fuse during routine maintenance. Replace immediately if short-circuit protection is triggered.
• Q4. Does it include built-in diagnostics?
  Yes. It has red (SF), green (PWR), and backup (FSG) LEDs that indicate operational and fault status.
• Q5. What experience tips help improve system reliability?
  Use stable voltage sources and certified circuit breakers to reduce downtime and extend module lifespan.
