ATV71HD11N4 Schneider Electric Variable Speed Drive Overview
ATV71HD11N4 is a 11 kW / 15 HP drive for advanced machines. It works on 380-480V, 3-phase supply and includes an EMC filter. Easy to install and simple to control. Written by Powergear X Automation.
Main Highlights
- Motor Power: 11 kW (15 HP)
- Voltage: 380–480 V AC ±10%
- Integrated EMC Filter
- Max Cable: 50 m shielded / 100 m unshielded
- Output Frequency: 0.1 to 599 Hz
- With heat sink design
- Noise level: 57.4 dB
Performance Data
- Rated current: 21 A at 460 V
- Switching frequency: 1–16 kHz
- Speed range: 1–100 open loop / 1–1000 closed loop
- Torque accuracy: ±15% (open loop)
- Transient torque: up to 220% for 2 seconds
- Efficiency class: IEC IE2
Control Features
- Vector control without feedback
- Sensorless flux vector control
- Adjustable PI control loop
- V/F profiles available
Inputs and Outputs
- 7 digital inputs
- 2 analog inputs (voltage or current selectable)
- 2 relay outputs
- 1 analog output (0–10V or 0–20mA)
- Integrated safety STO & PWR logic input
Communication Supported
- Modbus via RJ45
- CANopen via SUB-D 9
- Multiple communication card options
Environmental Specs
- Operating temperature: –10 to 50°C
- Storage temperature: –25 to 70°C
- Humidity: 5–95%, no condensation
- Operating altitude: up to 1000 m without derating
Physical Information
- Size: 295 × 213 × 210 mm
- Net weight: 8 kg
- Protection rating: IP20
Warranty & Delivery
- 12-month standard warranty
- Fast international shipping
- FedEx / UPS / DHL available
Why Choose This Model
- High overload performance
- Suitable for demanding industrial equipment
- Supports both synchronous and asynchronous motors
- Easy commissioning
- Wide expansion card support
Contact & Support
- Email: sales@powergearx.com
- WhatsApp: +86 18030005825
FAQ
- Q1: What type of motors can ATV71HD11N4 run?
A1: It supports asynchronous and synchronous motors, and works in vector or V/F mode. - Q2: Can the drive handle heavy load starting?
A2: Yes, it provides up to 220% torque for short periods, suitable for tough startup conditions. - Q3: Is an encoder required for operation?
A3: No, it can run in open loop, but an encoder improves accuracy when installed. - Q4: What is the shortest stop method?
A4: DC injection braking gives fast and controlled stopping. - Q5: What industries commonly use this model?
A5: Common fields include cranes, conveyors, material processing, machine tools, and industrial automation lines.
