Schneider Electric 140DDO88500 Wide Voltage Output Module

The Schneider Electric 140DDO88500 delivers exceptional flexibility for industrial automation with its wide voltage range capability. This 12-point DC output module handles high-voltage applications with superior reliability.

Technical Specifications

• Brand: Schneider Electric
• Model: 140DDO88500
• Output Type: DC Discrete, Negative Logic
• Number of Points: 12 points
• Voltage Range: 24-125V DC (19.2-156.2V limits)
• Current Rating: 0.75A per point, 3A per group, 6A total
• Surge Current: 4A for 1ms
• Response Time: 1ms (both transitions)
• Isolation: 2500Vrms (channel to bus), 1200Vrms (group)
• Switching Frequency: ≤50 Hz
• Backplane Current: 375-650mA @ 5V
• Operating Temperature: 0°C to 60°C
• Power Dissipation: 1W + (0.77 × points on)
• Weight: 18.2 oz (515g)
• Dimensions: 12.28″ × 6.42″ × 1.77″

Protection Features

• Short-circuit protection
• Varistor overvoltage protection per group
• 4A fuse protection
• 4kV contact ESD protection
• 8kV air discharge protection
• Unlimited load inductance with diode protection

Load Compatibility

• Tungsten Loads: 8W @ 24V, 41W @ 115V, 46W @ 130V
• Inductive Loads: Unlimited with protection diode
• Resistive Loads: Full current rating
• LED Loads: Compatible with wide voltage range
• Solenoid Loads: Surge current supported

Certifications & Compliance

• FM Class 1 Division 2
• UL 508, CSA C22.2 No 142
• GOST, RMRS, C-tick
• CE marked
• Industrial safety standards
• Global marine certifications

Status Indicators

• 12 green LEDs for output status
• Green Active LED for bus communication
• Red Fault LED for overcurrent conditions
• Real-time diagnostic monitoring
• Visual fault identification

Shipping & Support

• Single unit packaging
• Global shipping: FedEx, UPS, DHL
• Delivery: 3-5 business days
• Warranty: 12 months
• Technical support available
• Return policy: Not available
