Schneider Electric 140DDO35301 DC Output Module
The Schneider Electric 140DDO35301 offers high-density 24V DC output control for Quantum systems. This 32-point module provides reliable switching with fast response times.
Technical Specifications
- Brand: Schneider Electric
- Model: 140DDO35301
- Type: 32-point DC Output Module
- Voltage: 24V DC (19.2-30V range)
- Current: 0.5A per point, 4A per group
- Response: 0.1ms (off), 1ms (on)
- Isolation: 1780V to bus, 500V between groups
- Protection: 5A fuses per group
- Certifications: FM Class 1 Div 2, GOST, UL, CSA
- Warranty: 12 months
Performance Data
- Total module current: 16A maximum
- Voltage drop: <0.4V at 0.5A
- Leakage current: 1mA maximum
- Surge current: 2A capability
- Power dissipation: 5W typical
- Backplane current: 330mA
Packaging & Shipping
- Package: Single unit
- Dimensions: 31.2 x 16.3 x 4.5 cm
- Weight: 440 grams
- Carriers: FedEx, UPS, DHL
- Service: Global express available
Frequently Asked Questions
- What is the output type?
Positive logic (source) outputs – they supply current. - How fast is the response time?
Very fast: 0.1ms to turn off, 1ms to turn on. - What protection is provided?
5A fuses per group and 1780V isolation protection. - What is the maximum load current?
0.5A per point, 4A per group, 16A total module. - What certifications does it have?
FM Class 1 Division 2, GOST, UL508, and CSA.
