BMXSDI1602 Modicon X80 Safety Input Module with Conformal Coating

Schneider Electric BMXSDI1602: Reliable 16-Channel Safety Input Module

The BMXSDI1602 discrete input module delivers robust performance for Modicon X80 systems. This 16-input module handles 24V DC signals in demanding industrial environments. It features advanced diagnostics and conformal coating protection.

📊 Technical Specifications

• Brand: Schneider Electric
• Model: Modicon X80 BMXSDI1602
• Input Voltage: 24V DC (19-30V range)
• Input Current: 3.2 mA per channel
• Response Time: 6ms typical and maximum
• Operating Temperature: -25°C to 60°C (-13°F to 140°F)
• Power Consumption: 3.57W total dissipation
• Protection Rating: IP20 with conformal coating
• MTBF: 265,000 hours reliability
• Compatibility: 2-wire/3-wire proximity sensors

🛡️ Environmental Durability

• Resists gas, dust, sand, and fungal conditions
• Operates at altitudes up to 2000 meters without derating
• Withstands vibration up to 3gn and shock up to 15gn
• Maintains performance in 5-95% humidity environments
• Dielectric strength rated at 1500V AC for 1 minute

📦 Package & Shipping Information

• Single unit package dimensions: 26×18×5.5 cm
• Unit package weight: 338 grams
• Bulk options: 8-unit and 64-unit cases available
• Shipping carriers: FedEx, UPS, DHL express delivery
• 12-month manufacturer warranty included

❓ Frequently Asked Questions

• What types of sensors work with this module?
  The BMXSDI1602 supports 2-wire and 3-wire proximity sensors meeting IEC 60947-5-2 standards.
• How does the module detect sensor faults?
  It monitors voltage thresholds, detecting faults below 14V DC and normal operation above 18V DC.
• Can inputs be paralleled for higher current applications?
  Yes, the module supports input paralleling for flexible configuration.
• What is the input impedance value?
  Each channel has 7500 Ohm input impedance for stable signal reading.
• Is external overload protection required?
  The module includes built-in 0.5A fast-blow protection, but additional external protection may be needed for specific applications.
