Bently Nevada 3500/61-04-01 Temperature Monitor

• Manufacturer: Bently Nevada
• Product No.: 3500/61-04-01
• Product Type: Temperature Monitor with Recorder Outputs
• Made in: U.S.A
• Condition: New & Original, Factory Sealed
• Warranty: 12 Months

Shipping Options

• Fast worldwide delivery via FedEx, UPS, or DHL.

I/O Configuration

• Type: TC Isolated I/O Module (External)
• Approval: CSA/NRTL/C (Class 1, Div 2)

Key Technical Features

• Accepts 1–6 RTD or TC inputs
• Input impedance: 10 MΩ per lead
• Power use: 9 W nominal
• System isolation: 500 VDC
• Channel isolation: 250 VDC
• RTD current: 925 µA ±15 µA at 25°C
• Recorder output: 4–20 mA per channel, 0–12 VDC load range
• Accuracy: ±1°C to ±3°C depending on configuration
• Signal resolution: 1°C or 1°F

Supported Sensors

• Thermocouples: Type E, J, K, T
• RTDs: 100Ω, 120Ω, 10Ω – 3-wire or 4-wire
• Temperature Range: -200°C to +1370°C

Alarm Settings

• Alert and Danger thresholds adjustable via software
• Setpoints: 0–100% of full-scale range
• Delay time: 1–60 seconds (Alert), 0.5–60 seconds (Danger)

Environmental & Physical Specs

• Operating temp: -30°C to +65°C
• Storage temp: -40°C to +85°C
• Humidity: 95% non-condensing
• Monitor size: 241.3 × 24.4 × 241.8 mm
• I/O size: 241.3 × 24.4 × 99.1 mm
• Weight: 0.91 kg (Monitor), 0.45 kg (I/O)

Product Advantages

• Wide TC and RTD compatibility
• High measurement accuracy and fast response
• Low power use and excellent stability
• CSA/NRTL/C certified for industrial safety
• Easy configuration with 3500 Software
• Durable design for harsh environments

FAQ

• Q: How do I configure the Bently Nevada 3500/61-04-01 module?A: Use the 3500 Configuration Software to set full-scale ranges and alarm limits.
• Q: Can I mix RTD and TC inputs in one module?A: Yes, the module supports up to six mixed RTD or TC channels.
• Q: What happens if a channel is shorted?A: Recorder outputs are short-circuit protected; operation remains unaffected.
• Q: Is this monitor suitable for hazardous areas?A: Yes, CSA/NRTL/C Class 1, Div 2 approval ensures safe use in industrial zones.
• Q: How should the unit be shipped or stored?A: Keep it between -40°C and +85°C in dry packaging. Ship via FedEx, UPS, or DHL for safety.
