Bently Nevada 3500/61-02-00 Temperature Monitor | RTD TC Recorder Module

Bently Nevada 3500/61-02-00 Temperature Monitor

• Manufacturer: Bently Nevada
• Product No.: 3500/61-02-00
• Type: Temperature Monitor with Recorder Outputs
• Origin: Made in U.S.A
• Condition: 100% New & Original Factory Packing
• Warranty: 12 Months
• Shipping: FedEx / UPS / DHL Worldwide

Product Highlights

• 6 input channels for RTD or TC transducers
• High accuracy ±1°C (standard rack, external termination)
• Nominal power consumption: 9W
• Front panel LED indicators: OK / TX-RX / Bypass
• 4–20mA recorder output, unaffected by short circuit
• High input impedance: 10 MΩ per channel
• Cold Junction Compensation: ±1°C @25°C
• Resolution: 1°C or 1°F
• System isolation: 500Vdc; channel isolation: 250Vdc
• Alert and Danger alarms configurable 0–100% full-scale

Supported Transducers

• RTDs: 100Ω platinum (0.00385 & 0.00392), 120Ω nickel, 10Ω copper
• TCs: Type E (-100°C to +1000°C), J (-18°C to +760°C), K (-18°C to +1370°C), T (-160°C to +400°C)

Performance Details

• Accuracy: ±3°C typical at 25°C
• Alarm delay: 1–60s adjustable via software
• Voltage compliance: 0–12Vdc across 0–600Ω load
• RTD current source: 925 µA ±15µA @25°C
• Resolution: 0.3662 µA/bit ±0.15% at room temperature

Environmental & Physical

• Operating Temperature: -30°C to +65°C
• Storage Temperature: -40°C to +85°C
• Monitor Dimensions: 241.3 × 24.4 × 241.8 mm
• Monitor Weight: 0.91 kg
• I/O Module Dimensions: 241.3 × 24.4 × 99.1 mm
• I/O Weight: 0.45 kg

Suffix Configuration Tree

• I/O Module Type: 02 → RTD/TC Non-Isolated I/O Module
• External Termination: Supported
• Agency Approval: 00 → None

Key Advantages

• Reliable performance under wide temperature range
• Precision measurement with configurable alarms
• Compact size fits single full-height rack slot
• Fast, secure shipping by FedEx, UPS, and DHL
• Professional support: sales@powergearx.com | +86 18030005825

FAQs

Q1: What is the main function of the Bently Nevada 3500/61-02-00?
It monitors up to six temperature channels using RTD or TC sensors with high accuracy.

Q2: Can this monitor be configured without calibration?
Yes. Full-scale ranges are field-set via 3500 Configuration Software—no calibration needed.

Q3: What’s the maximum power draw of the module?
The nominal consumption is 9 watts, ideal for continuous industrial operation.

Q4: Is the 3500/61-02-00 suitable for extreme environments?
Yes, it operates from -30°C to +65°C and withstands storage down to -40°C.

Q5: How can I ensure accurate RTD readings in mixed systems?
Use standard platinum RTDs with 0.00385 alpha for best accuracy across all applications.
