Bently Nevada | 330930-065-03-CN 3300 XL Standard Extension Cable

Bently Nevada 330930-065-03-CN Extension Cable

Product Overview

The Bently Nevada 330930-065-03-CN is a 6.5-meter 3300 NSv extension cable. It features a non-armored design with a connector protector and is built for reliable performance in extreme environments.

Key Technical Specifications

• Model: 330930-065-03-CN
• Cable Length: 6.5 meters (21.3 feet)
• Cable Type: 75 Ω coaxial, FEP insulated
• Connector Option: Without stainless steel armor, with connector protector
• Shipping Weight: 1.5 kg
• Approval: Country-specific (CN)

Electrical Characteristics

• Center Conductor Resistance: 0.220 Ω/m (0.067 Ω/ft)
• Shield Resistance: 0.066 Ω/m (0.020 Ω/ft)
• Capacitance: 69.9 pF/m (21.3 pF/ft)
• Connector Material: Gold-plated brass

Installation Guidelines

• Make sure total cable length equals Proximitor Sensor system length
• Supports 0.2 to 1.5 mm² (16 to 24 AWG) wire
• Use shielded triad cable for field wiring
• Maximum field wiring length: 305 meters (1,000 feet)

Model Structure Explained

• 330930: NSv Extension Cable Series
• 065: 6.5 meters cable length
• 03: Without stainless steel armor, with connector protector
• CN: Country-specific approvals

Use Cases

• Small machinery vibration monitoring
• Compact rotating assets in oil and gas
• Environments with wide temperature shifts
• OEMs integrating sensors into constrained spaces

Package and Delivery

• What’s Included: Extension cable, silicone tape
• Certificate of Origin: Available upon request
• Warranty: 12 months
• Shipping Methods: FedEx, UPS, DHL
