Bently Nevada 330876-01-90-00-00 | 3300 XL Proximity Probe

Bently Nevada 3300 XL 50mm Probe: Extreme Environment Solution

Premium Protection & Performance

• New factory-sealed unit with 12-month warranty
• Built for 250°C (482°F) steam turbine environments
• Double-sealed tip blocks moisture entry
• 9-meter FluidLoc® cable for high-heat areas
• Easy cable routing with removable ClickLoc® collar

Complete Product Details

• Brand: Bently Nevada
• Model: 3300 XL 50mm Proximity Probe
• Full Part No: 330876-01-90-00-00

Part Number Decoder

• 330876 → Base Model
• -01 → ½-20 Thread Straight Exit
• -90 → 9.0 meter Cable (29.5 ft)
• -00 → High Temp FluidLoc® Cable
• -00 → Standard Certifications

Technical Specifications

• Resistance: 8.9Ω ±1.1Ω (9m cable)
• Temp Range: -35°C to +200°C (-31°F to 392°F)
• Max Temp: 250°C (482°F) for 24 hours
• Case: 1.99″ AISI 304 Stainless Steel
• Thread: 1/2-20 (0.75″ max depth)
• Cable: 75Ω Triaxial PFA FluidLoc®

What’s Included

• Probe with 9m cable
• Connector protectors
• Protector installation tool
• Locknut with safety wire holes

Shipping & Support

• Global delivery: FedEx, UPS, DHL
• Full 12-month warranty

Get Installation Help

• Download full installation guide: [Link to Manual]
• Compatible with all Bently Nevada 3300 XL systems

Expert FAQs

• Q: What thread type does this model have?
  A: ½-20 UNF straight exit thread with locknut
• Q: Is this 3300 XL 50mm probe waterproof?
  A: Yes, dual seals and FluidLoc® cable prevent water damage
• Q: What’s the maximum cable length available?
  A: This model has 9m cable – longest available option
• Q: Can I use this in explosive environments?
  A: No – suffix -00 indicates standard certifications only
• Q: Does warranty cover high-heat damage?
  A: Yes, 12-month warranty covers normal operation up to 200°C
