Bently Nevada | 330876-01-50-01-00 3300 XL Proximity Probe

Bently Nevada 3300 XL 50mm Probe: Heavy-Duty Machinery Monitoring

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL 50 mm Proximity Probe
• Part Number: 330876-01-50-01-00
• Probe Length: 5.0 meters (16.4 feet)
• DC Resistance: 7.6Ω ± 0.8Ω
• Thread Type: ½-20 UNF straight
• Case Material: 304 Stainless Steel
• Tip Material: PPS (Polyphenylene Sulfide)
• Cable Type: 75Ω Triaxial with PFA insulation

Suffix Code Breakdown

• 330876: Base model (3300 XL 50mm)
• -01: ½-20 Thread (Straight Exit)
• -50: 5.0 meter cable length
• -01: High Temp FluidLoc Armor
• -00: No agency approvals

Key Performance Data

• Case diameter: 1.99 inches
• Max thread engagement: 0.750 inches
• Storage temperature: -35°C to +200°C
• Cable lengths available: 1m, 5m, 9m
• Safety locknut with pre-drilled holes

Package Includes

• 3300 XL 50 mm Probe with 5m cable
• ClickLoc connector protectors
• Connector installation tool
• Factory packaging
• 12-month warranty card

Installation Notes

• For use with 5m Proximitor sensors only
• Max thread engagement 0.75 inches
• Apply connector protectors before installation
• Use safety wire through locknut holes

Expert Questions & Answers

• Q: What cable length options exist?
  A: This probe has 5m cable. Other models offer 1m or 9m.
• Q: Is this probe waterproof?
  A: Yes, dual seals and FluidLoc armor prevent moisture entry.
• Q: What’s the material of probe tip?
  A: PPS (Polyphenylene Sulfide) for high heat resistance.
• Q: Does it include installation hardware?
  A: Comes with safety locknut and connector tools.
• Q: What’s the temperature limit for storage?
  A: Same as operation: -35°C to +200°C.

Get Your Product Documents

• Full installation guide
• Technical specifications sheet
• Safety handling procedures
• Compatibility charts

Download Complete Manual Here
