Bently Nevada 330710-000-050-90-02-05 Armored M16 Probe

Long-Reach Armored M16 Probe for Heavy Industrial Monitoring

Introducing the Bently Nevada 330710-000-050-90-02-05. This is a heavy-duty solution from the 3300 XL series, combining a robust M16 thread with a full 9.0-meter armored cable. Designed for large-scale machinery where sensors are remote from control panels. Its compact 50mm case and armored construction withstand harsh plant environments. This USA-made probe carries multiple global safety approvals and is supplied as new, original stock with a 12-month warranty.

Comprehensive Technical Specifications

• Complete Part Number: 330710-000-050-90-02-05
• Manufacturer & System: Bently Nevada 3300 XL Probes
• Product Type: Armored 11mm Proximity Sensor for Large Shafts
• Industrial Mounting: M16 x 1.5 Coarse Thread, Fully Threaded Case.
• Compact Body: Short 50mm Overall Case Length.
• Extended Reach: Integral 9.0 Meter (29.5 ft) Armored Triaxial Cable.
• Connection: ClickLoc Connector (Ready for Immediate Connection).
• Electrical Check: Resistance: 8.5 Ohms ± 1.1 (for 9m length).
• Application Specifics: Min. Target: 30.5mm, Min. Shaft: 152mm (6″).
• High-Strength Mount: Recommended Torque: 21.1 N•m (187 in-lb).
• Environmental Rating: Operates from -52°C to +177°C.
• Certifications: Holds Multiple International Agency Approvals.

Installation & Best Practices

• The M16 thread requires a properly tapped hole in a substantial mounting boss.
• Plan the long armored cable route to avoid sharp bends and physical damage.
• Secure the cable with clamps at regular intervals to support its weight.
• This probe is ideal for large turbines, generators, and mills where long cable runs are necessary.
• Ensure the target shaft meets the minimum 152mm diameter for optimal accuracy.

Core Advantages for Demanding Applications

• All-in-One Durable Solution: Combines a heavy-duty thread, short body, armored cable, and long reach into a single, reliable assembly.
• Eliminates Intermediate Connections: The 9-meter integral cable often reaches the monitor directly, reducing potential failure points and signal loss.
• Built for Compliance: Multiple approvals facilitate use in regulated industries and hazardous locations worldwide.
• Superior Mechanical Protection: The armor safeguards the cable over long, exposed runs common in power plants and heavy industry.
• Engineered for Large Machinery: Specifically designed to provide stable, accurate signals on large-diameter rotating equipment.

Professional FAQs & Guidance

What types of machinery typically use this M16 armored long-cable probe?

Large steam turbines, hydroelectric generators, rolling mill drives, and major centrifugal compressors where the sensor is far from the junction box and the environment is demanding.

Why is the resistance higher for the 9-meter version?

The longer internal wiring in the cable adds resistance. The monitor is calibrated to accept this range (8.5 ± 1.1 Ohms) for proper operation.

Can this probe be used in groups for multi-channel vibration monitoring on a single shaft?

Yes, but careful spacing is required. The 152mm minimum shaft diameter guideline helps minimize electrical crosstalk between probes mounted close together.

What is the benefit of the “multiple approvals” option in practical terms?

It simplifies procurement and safety compliance audits. The probe can be installed in areas requiring ATEX, IECEx, or similar certifications without needing additional validation.

How do I order and what is the delivery and support process?

Contact us for the 330710-000-050-90-02-05. We provide quotes and ship quickly via FedEx, UPS, or DHL. Your purchase is protected by a 12-month warranty and includes full technical documentation.

Package Details & Guarantee

• Supplied Product: One Bently Nevada 330710-000-050-90-02-05 armored probe.
• Product State: 100% New, Original, in Factory Packaging.
• Warranty Period: Full 12-Month Manufacturer Warranty.
• Shipping Methods: Available for Expedited International Delivery.

For immediate assistance, technical data, or to place an order, please contact us.
