Product details
Cost-Effective Long-Range Vibration Sensing
The Bently Nevada 330707-00-25-90-01-00 offers reliable machinery monitoring without extra certification costs. This 9-meter probe features a standard cable and short case for versatile installations where agency approvals are not mandatory.
Product Model Decoder
Complete Part Number: 330707-00-25-90-01-00
- Core Part (330707): 3300 XL 11mm Probe, 5/8-18 UNF, No Armor
- Unthreaded (00): 0 inches
- Case Length (25): 2.5 inches
- Cable Length (90): 9.0 meters (29.5 feet)
- Connector (01): ClickLoc with Protector, Standard Cable
- Approvals (00): Not Required
Complete Product Specifications
- Manufacturer: Bently Nevada
- Product Line: 3300 XL Monitoring System
- Item Type: 11mm Proximity Probe
- Specific Model: 330707-00-25-90-01-00
- Mounting Thread: 5/8-18 UNF
- Probe Body: Short 2.5-inch 304 Stainless Steel
- Integrated Cable: 9.0m, Standard FEP, 75 Ω Triaxial
- End Connection: Miniature ClickLoc Coaxial with Cap
- Sensing Tip: PPS (Polyphenylene Sulfide)
- Electrical Resistance: 8.5 Ω ± 1.1 Ω (for 9m length)
- Operating Range: -51°C to +177°C
- Seal Type: Internal Viton O-ring (Not Pressure Tested)
- Installation Torque: 15.2 N•m Recommended / 45.2 N•m Max
- Cable Bend Radius: Minimum 25.4 mm (1.0 inch)
- Shipping Mass: 0.17 kg
Ideal Use Cases
- General-purpose vibration monitoring on pumps, fans, and motors.
- Applications where specific hazardous area certifications are not needed.
- Installations requiring a long cable run (9m) to the monitoring system.
- Locations with limited depth for probe mounting (short 2.5″ case).
- Cost-sensitive projects needing genuine Bently Nevada performance.
Expert Q&A for Smart Buyers
Specifications & Features
- What does “Agency Approval Option : 00” mean?
- This model does not carry specific third-party safety certifications (like ATEX, IECEx). It is for use in standard industrial areas, not classified hazardous locations.
Application & Suitability
- Is the standard cable on this 330707-00-25-90-01-00 okay for wet areas?
- The FEP-insulated cable is good for general factory conditions. For constant moisture or chemical spray, choose a model with FluidLoc cable (Option 11 or 12).
Installation Planning
- Can I cut and re-terminate the 9-meter cable if it’s too long?
- No. The probe is a sealed unit. Cutting the cable voids the warranty and changes its electrical characteristics, causing measurement errors.
Ordering & Warranty
- What is excluded from the 12-month warranty?
- Damage from improper installation, like over-torquing, misuse, or exposure to temperatures below -34°C before installation is not covered.
Logistics & Support
- How fast can I get the 330707-00-25-90-01-00 probe?
- We ship quickly worldwide. Select from FedEx, UPS, or DHL services at checkout. Delivery time depends on your location and chosen service.
Contact Us for More Details
For a quote or technical advice on the 330707-00-25-90-01-00, reach out to our team.
Email us at: sales@powergearx.com
Call or WhatsApp: +86 18030005825
