✅ Hazardous Area Reverse Mount Probe
This Bently Nevada 330706-005-046-90-00-05 is a certified 11mm reverse mount sensor. It is built for demanding installations in explosive atmospheres. The probe measures vibration from the back of machine casings. It is perfect for tight spaces in petrochemical and gas plants. This model delivers safety and reliability in critical applications.
🔐 Certified Configuration: 330706-005-046-90-00-05
- 330706 – 3300 XL 11mm Reverse Mount Series
- 005-046 – Configuration: Reverse Mount, M10x1 Thread
- 90 – Integrated Cable: 9.0 meters (Long Reach)
- 00 – Connector: ClickLoc Coaxial (Standard)
- 05 – Safety Certifications: CSA, ATEX, IECEx
📋 Performance & Construction
- Function: Reverse Mount Proximity Probe
- Manufacturer: Bently Nevada
- Product Family: 3300 XL 11mm
- Thread Size: M10 x 1.0 Metric
- Cable Insulation: FEP (Fluorinated Ethylene Propylene)
- Electrical Resistance: 5.9 Ω ± 0.5 Ω (per meter)
- Body Material: AISI 304 Stainless Steel
- Tip Material: Durable PPS Plastic
- Temperature Range: -51°C to +177°C
- Seal: Viton® O-Ring
- Mounting Torque: 7.5 N•m (66 in-lb) max
- Minimum Bend Radius: 25.4 mm
💡 Expert FAQ for This Model
What is the key difference between -00 and -05 approval options?
The “-05” suffix adds major hazardous area certifications (CSA, ATEX, IECEx). The “-00” model has no such approvals and is for standard areas only.
Why is the cable insulation FEP important?
FEP insulation offers excellent chemical and temperature resistance. It is crucial for reliability in harsh environments like refineries where oils and solvents are present.
Can this probe be used in Zone 0 hazardous areas?
Yes, when installed with approved intrinsic safety barriers per the manual, this “-05” certified probe is suitable for Zone 0, the most stringent hazardous area classification.
Is the 9-meter cable length a standard offering?
Yes, 9 meters is a standard long-length option for the 3300 XL system. It is designed specifically for use with the matching 9-meter Proximitor sensor.
How should I handle the cable during installation?
Avoid sharp bends. Maintain a minimum bend radius of 1.0 inch (25.4 mm). Secure the cable with clamps to prevent stress on the connector.
🛒 Ordering & Support Assurance
Ideal Use Case: Specify model 330706-005-046-90-00-05 for reverse mount applications in certified hazardous locations requiring a 9m cable.
