Product details
11mm Probe with Extended Unthreaded Body for Custom Mounts
Acquire the genuine Bently Nevada 3300 XL Proximity Probe, part 330703-050-120-10-02-00. This sensor is new, original, and supplied in factory packaging. It is backed by a comprehensive 12-month manufacturer warranty.
This unique configuration features a 50mm unthreaded section on the case. This allows for flexible mounting through thick panels or custom adapters. With a 120mm overall case and 1-meter cable, it is a versatile solution for specialized machinery setups.
Detailed Configuration & Specifications
- Complete Model Code: 330703-050-120-10-02-00
- Brand: Bently Nevada
- System Series: 3300 XL Vibration Monitoring
- Probe Type: 11mm Diameter Triaxial Sensor
- Thread Type: M14 x 1.5 at the base.
- Key Design: 50 mm Unthreaded Shank Length.
- Total Case Length: 120 mm from tip to thread end.
- Integrated Cable: 1.0 Meter (3.3 Feet) Standard.
- Cable Spec: Triaxial, 75 Ohm, FEP Insulation.
- Connector: Standard ClickLoc (without protector).
- Agency Certs: Standard Model, No Special Approvals.
- Electrical Characteristic: 5.9 Ohms DC Resistance (±0.5Ω).
- Magnetic Immunity: Very low sensitivity to AC field interference.
- Robust Materials: 304 SST Body with Chemical-Resistant PPS Tip.
- Installation Torque: Recommended 21.1 N·m (187 in-lb).
- Thread Limit: Maximum 21 mm of engaged threads.
- Operating Range: Wide from -52°C to +177°C.
- Seal Advisory: Do not subject to temperatures below -34°C.
Why This Probe Is Different
- Adaptable Mounting: The long unthreaded section lets you pass the probe through a thick mounting bracket before the threads engage, offering great installation flexibility.
- Secure Fit: The 120mm overall length provides a sturdy, stable mounting in deep holes or heavy machinery housings.
- Simplified Connection: Standard ClickLoc connector ensures easy and reliable mating with extension cables.
- General Purpose Use: Ideal for most industrial environments where special fluid resistance or certifications are not required.
Your Order Includes
- The Product: One Bently Nevada 330703-050-120-10-02-00 vibration probe.
- Condition Guarantee: 100% new and original, never used.
- Warranty Assurance: Full 12-month coverage for peace of mind.
- Fast Delivery: Shipped worldwide via reliable carriers like FedEx, UPS, and DHL.
Technical Guidance & FAQs
Design & Selection
- What is the purpose of the 50mm unthreaded section?
- This smooth section allows the probe to pass through a mounting adapter, spacer, or a thick machine wall. The threads only engage at the end, letting you position the tip precisely regardless of mounting material thickness.
- Is the ClickLoc connector on this model different from others?
- This model uses the standard ClickLoc connector (option -02). It does not have the external protective shell found on option -01 or -11. It is slightly more compact.
Application & Use
- Can I use this probe in a high-vibration environment like a fan drive?
- Yes. The robust 11mm design and secure M14 thread are well-suited for high-vibration applications. Ensure it is properly torqued to 21.1 N·m.
- Our mounting plate is 30mm thick. Will this probe work?
- Yes. The 330703-050-120-10-02-00 is ideal. The 50mm unthreaded section is longer than your 30mm plate, so the probe will fit through, and the threads will engage securely on the other side.
Purchasing Process
- Do you offer volume pricing for plant-wide refurbishment projects?
- Yes. We provide competitive pricing for bulk orders. Contact us with your required quantity of the 330703-050-120-10-02-00 and project timeline for a customized quote.
