Bently Nevada 330302-000-011-20-90-01-00 High Temperature Probe

Bently Nevada 3300 High Temperature Probe: Precision Monitoring for Extreme Environments

Industrial-grade proximity sensor for high-heat applications with armored cable protection.

Full Model Suffix: 330302-000-011-20-90-01-00

• Unthreaded length: 000 (0mm)
• Case length: 011 (11mm)
• Hardline length: 20 (2.0m/6.6ft)
• Total length: 90 (9.0m/30ft)
• Cable armor: 01 (Stainless steel)
• Agency approval: 00 (Not required)

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 High Temperature Probe
• Part No.: 330302-000-011-20-90-01-00
• Temperature range: -34°C to +350°C (-30°F to 662°F)
• Sensitivity (ISF): 3.94 V/mm ±9.65%
• Linearity (DSL): < ±78μm (±3.1 mils)
• Frequency response: 0-6 kHz (±3dB)
• Probe resistance: 5.82 Ω (2m length)
• Min. target size: 30.5mm (1.2in) diameter
• Weight: 117 g/m cable + 12 g/cm case

Environmental Durability

• Operates at 350°C continuous temperature
• Stainless steel armor protects against physical damage
• Maintains accuracy within ±30% from 22°C to 350°C

Installation & Compatibility

• Min. shaft diameter: 152mm (6.0in)
• Works with 305m (1000ft) field wiring
• Compatible with Bently Nevada monitoring systems

Package & Warranty

• Probe with 9m armored extension cable
• 12-month warranty
• Shipping: FedEx, UPS, DHL worldwide

FAQ

• Q: Maximum cable length?
  A: 305m (1000ft) with signal stability
• Q: Minimum target material?
  A: Ferrous steel (30.5mm min. diameter)
• Q: Calibration required?
  A: Pre-calibrated at factory (±9.65% tolerance)
