Bently Nevada 330191-00-08-10-00 8mm Industrial Proximity Sensor

Bently Nevada 330191-00-08-10-00 Proximity Probe Overview

The 330191-00-08-10-00 from Bently Nevada offers accurate, rugged, and reliable shaft position sensing. Built for critical machinery, it uses advanced TipLoc and CableLoc technologies to ensure long service life under harsh conditions.

• Manufacturer: Bently Nevada
• Model: 330191-00-08-10-00 — 3300 XL 8 mm ETR Probe
• Condition: New & Original in Factory Packing
• Warranty: 12 Months

Main Benefits

• Compact Design: 1.0 m total length for easy routing in tight installations.
• Strong CableLoc System: 330 N pull strength to secure cable connection.
• Durable Materials: PPS tip with stainless steel case resists corrosion and vibration.
• Stable Output: 50 Ω output resistance ensures consistent signal quality.
• FluidLoc Ready: Optional protection prevents oil leakage through cable interior.

Technical Specifications

• Probe Type: 8 mm unarmored ETR proximity probe
• Thread: 3/8-24 UNF with 0.563 in maximum engagement
• Unthreaded Length: 0.0 in minimum
• Overall Case Length: 0.8 in
• Total Length: 1.0 m (3.3 ft)
• Probe DC Resistance: 7.59 ±0.50 Ω
• Operating Voltage: -17.5 to -26 Vdc, 12 mA max
• Sensitivity: <2 mV output change per volt input change
• Output Resistance: 50 Ω nominal
• Tensile Strength: 330 N probe to lead, 270 N connector pull

Material & Cable Information

• Tip Material: PPS (Polyphenylene Sulfide)
• Case Material: AISI 303 or 304 stainless steel
• Standard Cable: 75 Ω FEP triaxial cable (1.0 m)
• Extended Temp Cable: PFA triaxial for high-temperature zones
• Connector: Gold-plated brass or beryllium copper
• Max Connector Torque: 0.565 N·m (5 in·lbf)

Environmental Ratings

• Temperature Range: -55°C to +232°C (T1 Class)
• Weight: Approx. 323 g/m
• Seal: Viton® O-ring, not pressure tested
• Protection: Designed for differential pressure sealing
• Cable Insulation: Resistant to oil, heat, and mechanical stress

Ordering Tree (Suffix Explanation)

• 330191 — 3300 XL 8 mm Probe Series
  • 00 — No unthreaded section (0.0 in)
  • 08 — 0.8 in overall case length
  • 10 — 1.0 m total probe length
  • 00 — No agency approval required

Applications

• Designed for turbines, compressors, and high-speed rotating machinery.
• Ideal for monitoring shaft vibration and axial position in critical assets.
• Used in refineries, power plants, and industrial automation systems.

Shipping & Packaging

• Factory-sealed packaging for moisture protection.
• Includes probe, mounting washer, and installation guide.
• Global delivery via FedEx, UPS, or DHL with tracking.
• 1-year limited warranty covers manufacturing defects.

Professional FAQ

• Q: Is this probe compatible with the 5 m Proximitor sensor?
• A: No, this model is optimized for 1 m system configurations.
• Q: Can I use the probe without extension cables?
• A: Yes, one-meter probes connect directly to the Proximitor unit.
• Q: How should I torque the connector during installation?
• A: Tighten to 0.565 N·m to ensure stable contact without over-stress.
• Q: What maintenance is required?
• A: Inspect cable integrity and resistance annually to maintain accuracy.
• Q: Can it handle high vibration environments?
• A: Yes, the PPS tip and stainless body provide strong vibration resistance.
