Overview

Bently Nevada offers the 330140 – 10 – 15 – 01 – 00, a 3300 XL 8 mm Probe without armor produced in the U.S.A. Customers have the option to add a Certificate of Origin (COO). This probe shows improvements over previous models. Thanks to the patented TipLoc molding and CableLoc design, it has better performance. Also, the optional FluidLoc cable can prevent liquid leakage.

Technical Specification

• Brand: Bently Nevada
• Model: 330140 – 10 – 15 – 01 – 00 (3300 XL 8 mm Probe without armor)
• Product No. Suffix Meanings:
  • “10” indicates an overall case length of 1.0 in.
  • “15” represents a total length option of 1.5 meters (4.9 feet).
  • “01” stands for a miniature coaxial ClickLoc connector with a connector protector and a standard cable.
  • “00” means no agency approval is required.
• Resistance: For a 1.5 – meter probe, the nominal DC resistance from the center conductor to the outer conductor is 7.73 ± 0.50 Ω.
• Incremental Scale Factor (ISF):
  • In a standard 5 – or 1 – meter system, it is 7.87 V/mm (200 mV/mil) ± 5% within the 80 – mil linear range from 0°C to +45°C.
  • In a standard 9 – meter system, it is 7.87 V/mm (200 mV/mil) ± 6.5% under the same measurement conditions.
  • For the Extended Temperature Range (ETR) of 5 – and 9 – meter systems, it is also 7.87 V/mm (200 mV/mil) ± 6.5%.

Contact Information

For any inquiries regarding this product, please contact sales@powergearx.com

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
