Bently Nevada 330103-17-23-05-02-05 Probe | 8mm Vibration Sensor with ATEX

Product Overview: Bently Nevada 3300 XL 8mm Probe

This is the Bently Nevada 330103-17-23-05-02-05, a high-precision 8mm eddy current proximity probe. It is essential for monitoring vibration and position on critical machinery like turbines and compressors. Its robust design ensures reliable performance in tough industrial conditions.

Key Features & Model Breakdown

• Core Product: 3300 XL 8 mm Probe, M10x1 thread
• Model Suffix Explained:
  • -17: Unthreaded Length = 170 mm
  • -23: Overall Case Length = 230 mm
  • -05: Total Cable Length = 0.5 meter (1.6 ft)
  • -02: Connector = Miniature Coaxial ClickLoc (Standard Cable)
  • -05: Approvals = CSA, ATEX, IECEx

Technical Specifications

• Brand & Model: Bently Nevada 330103-17-23-05-02-05
• Measurement Range: 2.0 mm (80 mils) linear range
• Sensitivity: Standard 200 mV/mil (7.87 V/mm)
• Gap Setting: 1.27 mm (50 mils) for -9 Vdc output
• Probe Resistance: 7.45 Ω ± 0.50 Ω (for 0.5m cable)
• Temperature Range: -52°C to +177°C (Standard)
• High Temp Option: Tip can handle up to +218°C
• Case Material: AISI 303/304 Stainless Steel
• Tip Material: Polyphenylene Sulfide (PPS)
• Sealing: Viton® O-ring for pressure differential
• Safety Ratings: Approved for Hazardous Areas (Zone 0/1/2)
• Cable Length: 0.5 meter with ClickLoc connector
• Thread Size: M10 x 1 with 15mm max engagement

FAQ – Frequently Asked Questions

Product Selection & Ordering

• This model 330103-17-23-05-02-05 has a 0.5m cable. Can I get a longer one?
• Yes. The “-05” in the suffix is the cable length option. We offer other standard lengths. Please contact us for different options like 1.0m or 5.0m cables.
• What does the “ClickLoc” connector mean for installation?
• The ClickLoc connector provides a secure, quick-connect interface. It reduces installation time and ensures a proper connection every time. It mates with matching Bently Nevada junction boxes.

Application & Performance

• Can I use this 8mm probe for thrust position measurement?
• Yes. The 330103-17-23-05-02-05 probe is commonly used for both radial vibration and axial (thrust) position monitoring when used in a dual-channel configuration.
• Why is the probe resistance important?
• The system’s proximitor is calibrated for a specific probe resistance range. Using a probe outside this range (like 7.45Ω ±0.5Ω for 0.5m) can cause measurement errors.

Service & Support

• What is the warranty and how do you ship?
• This product includes a 12-month warranty. We ship globally via reliable carriers like FedEx, UPS, and DHL for fast delivery to your location.

Need Help Ordering?

Confirm your system needs an 8mm probe with M10 thread and a 0.5m ClickLoc cable. The -05 approval suffix is key for hazardous locations. For custom needs, contact our experts.
