Product details
Bently Nevada Vibration Probe with Long Unthreaded Section
Optimized 3300 XL 8mm Proximity Probe for precise positioning. Model 330103-07-18-10-02-00 features a 70mm unthreaded barrel and 180mm total case. Ideal for applications requiring exact gap setting without thread interference.
Detailed Product Configuration
- 330103 – 3300 XL 8mm Probe, M10x1
- 07 – Unthreaded Length: 70mm Smooth Section
- 18 – Total Case Length: 180mm
- 10 – Integrated Cable: 1.0 meter (3.3 feet)
- 02 – Termination: Miniature ClickLoc Connector
- 00 – Certifications: No Agency Approvals Required
Essential Technical Parameters
- Brand: Bently Nevada
- System: 3300 XL Monitoring
- Part Number: 330103-07-18-10-02-00
- Function: 8mm Proximity Vibration Sensing
- Linear Detection Range: 2.0 mm
- Standard Gap Setting: 1.27 mm (50 mils)
- Probe DC Resistance: 7.59 Ω ± 0.50
- Case & Tip: SST Body, PPS Tip
- Internal Seal: Viton O-Ring
- Temperature Rating: -52°C to +177°C
Mounting & Mechanical Details
- Thread Type: M10 x 1.0 Metric
- Engagement Limit: Maximum 15 mm
- Installation Torque: 11.2 N•m (100 in•lbf)
- Initial Threads: Use 7.5 N•m for First Three
- Humidity Performance: Stable in High Humidity
Safety & Application Notes
- Approval Status: 00 = No Specific Certifications
- Wiring Compatibility: Up to 305m to Monitor
- Target Applications: Non-Hazardous Areas, General Industry
- Sealing Note: Not Pressure Tested by Default
What You Receive & Support
- One Authentic 3300 XL 8mm Proximity Probe
- Manufacturer Specifications
- 12-Month Product Warranty
- Fast Global Shipping: FedEx, UPS, DHL Available
- Technical Consultation: Free Application Support
Frequently Asked Questions
What is the purpose of a 70mm unthreaded section?
The long smooth section ensures the probe tip is correctly positioned before the threads engage. This guarantees the measurement gap is set precisely, independent of thread depth.
Is this probe suitable for hazardous areas?
No. Approval code “00” means it has no formal hazardous area certifications. Use this probe only in general-purpose, non-hazardous locations.
How does the 1.0m cable length compare to others?
1.0 meter is a popular standard length. It offers a good balance, providing enough cable for routing without excessive bulk, suitable for many machine layouts.
What is a key installation tip for this specific design?
When mounting, first thread the probe in by hand until the 70mm unthreaded section contacts the mounting surface. Then, use the gap setting tool to achieve the exact 1.27mm distance to the target.
When should I choose this model over a fully-threaded one?
Choose the 330103-07-18-10-02-00 when your mounting hole depth is variable or unknown. The long unthreaded section makes final gap adjustment easier and more reliable.
Need advice on selecting the right probe for a non-hazardous area? Contact our experts: sales@powergearx.com or +86 18030005825.
