Bently Nevada 330103-00-06-90-02-00 Vibration Probe | Long 9m Cable for Easy Install

Precision Machinery Monitoring: Bently Nevada 3300 XL Probe

This product is the 330103-00-06-90-02-00. It is an 8mm proximity probe from Bently Nevada. It offers reliable vibration measurement. This model features a long 9-meter cable. It is perfect for installations where the sensor is far from the connection point.

Your Probe’s Build Code: 330103-00-06-90-02-00

• Core Model 330103: 3300 XL 8 mm Probe, M10x1 thread, no armor.
• Unthreaded Length 00: 0 mm. The case is fully threaded for mounting.
• Case Length 06: 60 mm overall length for deeper mounting needs.
• Cable Length 90: 9.0 meters (29.5 ft) integrated cable. Reduces extra wiring.
• Connector Type 02: Standard Miniature ClickLoc connector.
• Agency Approval 00: Standard model. No hazardous area certifications.

Essential Technical Specifications

• Manufacturer & Model: Bently Nevada 330103-00-06-90-02-00
• Product Type: 3300 XL Series 8mm Proximity Transducer
• Key Operational Data:
  • Linear Measuring Range: 2.0 mm (80 mils).
  • Optimal Gap Setting: 1.27 mm to achieve -9 Vdc output.
  • Probe DC Resistance: 9.87 Ω ± 0.50 Ω (for the 9.0m cable).
  • Frequency Response: Consult manual for graphs with long cables.
• Robust Construction:
  • Housing: Durable AISI 303/304 Stainless Steel.
  • Tip: Wear-resistant Polyphenylene Sulfide (PPS).
  • Sealing: Viton® O-ring for environmental protection.
• Environmental Limits:
  • Operating Temperature: -52°C to +177°C (Standard).
  • Extended Tip Temp: Up to +218°C.
  • Humidity: Stable performance (<3% change) at 93% RH.
• Installation Details:
  • Mounting Thread: M10 x 1. Max 15 mm engagement.
  • Field Wiring: Can extend up to 305m with shielded cable.
  • System Compatibility: Designed for use with 3300 XL Proximitors.

Package, Warranty & Logistics

• Includes: One probe with 9.0m attached cable and ClickLoc connector.
• Quality Promise: Backed by a 12-month manufacturer warranty.
• Global Delivery: Shipped promptly via FedEx, UPS, or DHL services.

Pro Advice: Frequently Asked Questions

About This Specific Model

Q: Why does this probe have a 9-meter cable?

A: The long 9.0m cable (code ’90’) is for direct long-distance runs. It connects the probe to the junction box without a splice.

Q: What does “Agency Approval 00” mean?

A: It means this 330103-00-06-90-02-00 is a standard version. It does not have CSA, ATEX, or IECEx certifications. Use it in non-hazardous areas.

Installation & Application

Q: How does the 60mm case length affect installation?

A: The 60mm length provides more threading. It is good for thicker mounting brackets or housings.

Q: The resistance is different from shorter probes. Is this normal?

A: Yes. The nominal probe resistance increases with cable length. 9.87 Ω for this 9m model is correct and expected.

Purchasing & Support

Q: What are the shipping and warranty terms?

A: Your purchase includes a 12-month warranty. We ship worldwide using reliable couriers like DHL, UPS, or FedEx.

Ready to Order or Have Questions?

Contact our sales team for the 330103-00-06-90-02-00 or other Bently Nevada parts.
