Bently Nevada 330102-30-65-10-02-CN | 8mm Armored Vibration Sensor

Product Overview

The Bently Nevada 3300 XL 8mm Proximity Probe is designed for precise shaft vibration and position monitoring. It protects critical machinery from unexpected downtime. The armored design ensures durability in tough industrial settings.

Key Features & Benefits

• Armored Protection: Metal armor shields the cable from damage.
• Long Sensing Range: 2mm linear range for accurate measurement.
• Wide Temperature Operation: Functions from -52°C to +177°C.
• Easy Connection: Miniature ClickLoc connector for secure mating.
• Safe for Hazardous Areas: Meets intrinsic safety standards.

Detailed Technical Specifications

• Brand & Model: Bently Nevada 330102-30-65-10-02-CN
• Model Breakdown:
  • 330102 = 3300 XL 8mm Probe with Armor
  • 30 = 3.0 in Unthreaded Length
  • 65 = 6.5 in Overall Case
  • 10 = 1.0 Meter Cable
  • 02 = ClickLoc Connector
  • CN = Country Specific Approval
• Electrical Data
  • Probe Resistance (RPROBE): 7.59 ± 0.50 Ω
  • Impedance: Standard 3-conductor system
  • Field Wiring: Up to 305 meters max
• Mechanical & Sensing Data
  • Thread Size: 3/8-24 UNF
  • Linear Range: 2.0 mm (80 mils)
  • Recommended Gap: 1.27 mm (50 mils) for -9 Vdc
• Environmental Ratings
  • Operating Temp: -52°C to +177°C
  • Seal Warning: Avoid below -34°C
  • Humidity: Less than 3% ASF change at 93%
  • Cable: Standard triaxial
• Safety Certifications
  • Approvals: CN (Country Specific)
  • Hazardous Area: Complies with AEx/Ex ia, nA, ec standards

Installation & Setup Notes

• Set probe tip gap to 1.27 mm (50 mils) for standard vibration measurement.
• Maximum thread engagement is 0.563 inches. Do not over-tighten.
• Use shielded triad cable (16-24 AWG) for field wiring.
• Keep wiring runs under 305 meters for best signal quality.
• Avoid exposing the probe to temperatures below -34°C to protect the seal.

Compatibility Information

This 330102 probe pairs with Bently Nevada 3300 XL Proximitor sensors. The 1-meter cable version is universal. Note: 5-meter probes only work with 5-meter Proximitors.

Ordering & Support Details

• Warranty: Full 12-month manufacturer warranty.
• Shipping: Fast delivery via FedEx, UPS, or DHL.
• Packaging: Includes probe with armored cable and connector.
• Certifications: Supplied with country-specific agency approvals.

Frequently Asked Questions

Product Specifications

• What does the “CN” approval option mean?
• It means the probe meets specific safety standards required for use in certain countries. Check your local regulations.
• Can I use a 5-meter cable with any monitor?
• No. A 5-meter probe cable must be used with a matching 5-meter Proximitor sensor only.

Application & Selection

• Is this probe good for high-temperature applications?
• Yes. The standard probe works up to 177°C. For hotter areas up to 260°C, ask about the extended temperature version.
• How do I choose between 303 and 304 stainless steel cases?
• Both are strong. AISI 303 has better machinability. AISI 304 offers higher corrosion resistance. Choose based on your environment.

Expert Installation Tip

• Why is the initial gap setting so important?
• Setting the gap to 1.27 mm (50 mils) centers the shaft in the probe’s linear range. This gives you the most accurate vibration reading and prevents signal clipping.
