Overview
The 330104-00-13-10-02-CN is a precision – engineered 3300 XL 8 mm Proximity Probe by Bently Nevada, crafted in the U.S.A. It comes with an M10 x 1 threaded design and armor for durability. The probe can seal differential pressure between the tip and case using a Viton® O – ring.
Technical Specification
General
- Brand: Bently Nevada
- Model: 330104-00-13-10-02-CN
- Product Type: 3300 XL 8 mm Proximity Probes
Dimensions
| Parameter | Value |
|---|---|
| Unthreaded Length | 00 mm |
| Overall Case Length | 13 mm |
| Total Length | 1.0 meter (3.3 feet) |
Connector and Approval
| Parameter | Details |
|---|---|
| Connector and Cable – Type | Miniature coaxial ClickLoc connector, standard cable |
| Agency Approval | Country Specific Approval (CN) |
Electrical
| Parameter | Specification |
|---|---|
| Nominal Probe DC Resistance (1.0 m) | 7.59 ± 0.50 Ω |
| Proximitor Sensor Input | Accepts one non – contacting 3300 – series 5 mm or 3300 XL 8 mm Proximity Probe and Extension Cable |
| Power Supply (Non – incendive) | -17.5 Vdc to -26 Vdc, max 12 mA |
| Power Supply (With barriers) | -23 Vdc to -26 Vdc; > -23.5 Vdc may reduce linear range |
| Sensitivity | < 2 mV change in output voltage per volt change in input voltage |
| Output Resistance | 50 Ω |
For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
