Product details
Long Shank Probe for Deep Mounting Applications
This Bently Nevada 3300 XL 8mm Proximity Probe is built for deep installations. Model 330103-10-14-10-02-CN has a long 100mm smooth body. It fits through thick brackets or cooling jackets. The probe offers local market certifications. Get precise vibration data from hard-to-reach spots.
Model Number Details
- 330103 – 8mm Probe, M10x1
- 10 – Smooth Part: 100 mm
- 14 – Total Length: 140 mm
- 10 – Cable: 1.0 Meter
- 02 – Connector: ClickLoc
- CN – Certifications: Country Specific
Key Specifications
- Range: 2.0 mm.
- Gap: 1.27 mm.
- Temperature: -52°C to +177°C.
- Humidity: Excellent stability.
- Resistance: 7.59 Ω.
- Body: Stainless steel.
How to Install
- Slide the 100mm smooth section through your mount.
- Thread the end into the final hole.
- Do not exceed 15 mm thread depth.
- Tighten: 7.5 N•m then 11.2 N•m.
- Plug into your 3300 XL system.
FAQ
When do I need a 100mm smooth shank?
Use it for very thick mounting blocks. It is common in turbines and large compressors with deep housings.
What certifications are included?
The “CN” suffix means we can provide local approvals like NEPSI or EAC. Tell us your country’s requirement.
How long is the threaded section?
Total case is 140mm. 100mm is smooth. So, 40mm is threaded for secure fastening.
Can I use standard field wiring?
Yes. The probe connects to your existing 3300 XL monitor system with standard shielded cable.
What is your support policy?
We provide a 12-month product warranty. Fast shipping via FedEx, UPS, and DHL is available.
Ordering Information
Select this model for deep clearance mounts. Specify your required country certification.
