AMS A6500-UM Universal Measurement Card | Multi-Sensor Monitoring

A6500-UM Universal Measurement Card – Multi-Sensor Monitoring Solution

The A6500-UM Universal Measurement Card works with the AMS 6500 ATG protection system. This flexible card handles many sensor types in one compact unit. It connects easily to control systems using Modbus protocols. The card provides reliable monitoring for industrial machinery protection needs.

Technical Specifications

• Brand: AMS | Model: A6500-UM Universal Measurement Card
• Input Channels: 2 independent or combined channels
• Sensor Types: Eddy current, piezoelectric, seismic, LF, Hall-effect, LVDT, dynamic pressure
• Frequency Range: 0-18,750 Hz for most sensors
• Digital Inputs: 5 inputs, 13-32V high level, 0-3V low level
• Digital Outputs: 6 solid state relays, 19-32V DC, 100mA max
• Current Outputs: 2 channels, 0/4-20mA, ±1% accuracy
• Operating Temperature: -20°C to 70°C with cooling
• Power Consumption: Maximum 6W
• Communication: Modbus RTU, Modbus TCP/IP, USB
• Safety Standards: ATEX, IEC-Ex, CSA, UL, CCC, DNV GL

Sensor Input Details

• Eddy Current: -1V to -22V range, 0-18,750 Hz
• Piezoelectric: +1V to +23V range, 0-18,750 Hz
• Seismic: -10V to +15V range, 0-2,000 Hz
• LF Vibration: -11V to +11V range, 0-1,000 Hz
• Hall-effect: +1V to +22V range, 0-18,750 Hz
• VR Sensors: -22V to +22V range, 0-18,750 Hz

Output Specifications

• Two 0/4-20mA analog outputs with ±1% accuracy
• Six digital relay outputs, normally open type
• Two pulse outputs for frequency signals
• Raw signal outputs for each sensor input
• Modbus TCP/IP and Modbus RTU protocol support
• USB front panel connection for configuration

Environmental Ratings

• IP20 protection rating per IEC 60529
• Operating temperature: -20°C to 70°C with forced cooling
• Storage temperature: -40°C to +85°C
• 5-95% relative humidity, non-condensing
• Vibration resistant per IEC 60068-2-6
• Shock resistant: 150 m/s², 4000 shocks per axis
• Hazardous area certifications: ATEX, IEC-Ex, CSA

Certifications & Approvals

• CE Marking for European market
• ATEX for explosive atmospheres
• IEC-Ex international explosion protection
• CSA certification for North America
• UL certification for safety standards
• CCC for Chinese market
• DNV GL for marine applications
• SIL 2 capable per IEC 61508

Ordering & Shipping

• Product Model: A6500-UM Universal Measurement Card
• 12-month manufacturer warranty included
• Worldwide shipping via FedEx, UPS, DHL
• Standard delivery time: 2-4 weeks
• Emergency express shipping available
• Technical documentation provided
• Installation support available

Professional FAQ

• What makes the A6500-UM different from other measurement cards?

The A6500-UM supports seven sensor types in one card. This reduces your spare parts inventory. It provides maximum flexibility for different monitoring applications.

• Can I use this card in hazardous areas?

Yes, the card has ATEX, IEC-Ex, and CSA hazardous area certifications. It meets requirements for Zone 2 and Division 2 areas. Always check specific certification details for your application.

• How many machines can one A6500-UM card monitor?

The card has two independent channels. You can monitor two different measurement points. These can be on the same machine or different machines.

• What communication protocols does the card support?

The A6500-UM supports Modbus RTU and Modbus TCP/IP. It also has USB for direct computer connection. This ensures compatibility with most control systems.

• Is special software needed for configuration?

Yes, AMS provides configuration software. It works through the USB port or network connection. The software offers easy setup and real-time monitoring.
