Product details
Overview
The Allen-Bradley/Rockwell Automation PowerFlex 40P series, model 22D-B024F104, is a versatile adjustable frequency drive designed to efficiently control motor speed and torque in various industrial applications. It operates with a three-phase power source, offering precise regulation and control over a range of motor-driven systems. Ideal for programmable logic controller (PLC) systems, the 22D-B024F104 ensures smooth performance, high reliability, and robust environmental resistance, all within a compact, flange-mountable enclosure.
Technical Specifications
- Brand: Allen-Bradley (Rockwell Automation)
- Model: 22D-B024F104
- Series: PowerFlex 40P
- Frame Size: C
- Power Supply: Three-Phase, 240 Volts AC
- Output Current: 24 Amps
- Horsepower: 7.5 HP (5.6 kW)
- Enclosure Type: Open NEMA Type (Flange Mount, IP20)
- Control Methods: Sensorless Vector, Sinusoidal PWM, Volts/Hertz
- Output Frequency: Programmable, 0–500 Hz
- Weight: 2.2 lbs (1.0 kg)
- Dimensions:
- Width: 300 mm (11.81 in)
- Height: 325 mm (12.8 in)
- Depth: 244 mm (9.61 in)
- Operating Temperature: -10 to 50°C (14 to 122°F)
- Storage Temperature: -40 to 85°C (-40 to 185°F)
- Humidity: 0–95% (non-condensing)
- Shock Resistance: 15 G peak for 11 ms
- Vibration Resistance: 1 G peak (5 to 2000 Hz)
Ordering Information
To order the drive, include the following details:
- Part Number: 22D-B024F104
- Frame Size: C
- Enclosure: Flange Mount, IP20
Check official datasheet for more detailed information: PowerFlex 40P
