Overview
The Allen-Bradley PowerFlex 40P series offers reliable and efficient motor control solutions. The 22D-B017F104 model, a three-phase adjustable frequency drive, is designed to control the speed and torque of compatible motors in various industrial applications. With its compact Size B frame and IP20 rated enclosure, the drive is suitable for environments where space is limited but performance is crucial. It supports multiple control methods and is an ideal choice for applications requiring smooth, reliable motor control in a wide range of industries.
Technical Specifications
- Brand: Allen-Bradley (Rockwell Automation)
- Model: 22D-B017F104
- PowerFlex Series: PowerFlex 40P
- Frame Size: B
- Enclosure: Open NEMA Type – Flange Mount (IP20)
- Input Voltage: 240 Volts AC (Three-Phase)
- Input Power: 11.8 kVA
- Amperage: 17.5 A
- Output Power: 5 Horsepower (3.7 kW)
- Output Amperage: 17.5 A
- Frequency Range: 0 to 500 Hz
- Control Methods:
- Sinusoidal Pulse Width Modulation (SPWM)
- Volts per Hertz
- Sensorless Vector Control
- Operating Temperature: -10°C to 50°C
- Relative Humidity: 0 to 95% non-condensing
- Dimensions: 180 x 100 x 144.2 mm
- Overload Capacity:
- 150% for 1 minute
- 200% for 3 seconds
- Filter: No CE Compliant Filter
- Motor Protection: Class 10 motor overload, motor over-temperature protection (per NEC 430/430.125)
- Bus Voltage Trip Ratings: 405V DC (Over-voltage), 210V DC (Under-voltage)
- Power Dissipation: 235 Watts
- Mounting Type: Flange Mount (IP20 rated enclosure)
Ordering Information
- Catalog Number: 22D-B017F104
- Model: PowerFlex 40P Adjustable Frequency Drive
- Frame Size: B
- Enclosure Type: Open NEMA Type, Flange Mount (IP20)
Check official datasheet for more detailed information: PowerFlex 40P
