Allen-Bradley 294D-FD4P2Z-G2-3 ArmorStart LT Distributed Motor Controller VFD

Product Summary

• 294D-FD4P2Z-G2-3 delivers stable speed control, fast diagnostics, and reliable field performance.

Main Features

• The drive supports 0.5–2 Hp motors with V/Hz control for simple speed regulation.
• The unit meets IP66 / UL Type 4/12 for water and dust protection.
• The internal EMI filter reduces electrical noise in sensitive systems.
• EtherNet/IP or DeviceNet communication offers quick integration.
• DeviceLogix logic enables local control without constant PLC commands.
• LED indicators provide fast status checks during operation.

Technical Specs

• Brand: Allen-Bradley | Series: ArmorStart LT | Model: 294D-FD4P2Z-G2-3
• Voltage range: 400Y/230…480Y/277 V with −15% to +10% tolerance.
• Output current: 3.6 A for 2 Hp motors.
• Control power: External 24V DC, 275 mA nominal.
• Overload: 150% for 60 s or 200% for 3 s (Class 10).
• Frequency: 0–400 Hz with ±2% speed control accuracy.
• Carrier: 2–10 kHz, rated at 4 kHz use.
• Ride-through: 0.5 s minimum, 2 s typical.
• Max cable: 10 m CE, 14 m non-CE.
• Temperature: −20 to +40 °C; storage −25 to +85 °C.

Certifications

• Complies with UL 508C, CSA C22.2 No.14, EN/IEC 60947, and EN/IEC 61800 standards.
• Holds CE and cULus approvals for global industrial use.

Installation Guide

• Mount on a flat surface and keep room for airflow.
• Use ArmorConnect or conduit for sealed wiring.
• Wire L1/L2/L3 input and T1/T2/T3 motor output correctly.
• Apply stable 24V DC control power.
• Setup communication on DeviceNet or EtherNet/IP before running.
• Use line reactors in high-temperature setups.

Package Contents

• One ArmorStart LT unit with ordered options.
• Quick start guide and wiring instructions.
• Mounting hardware and enclosure gasket.
• Factory-installed quick disconnects when selected.
• Shipping via FedEx, UPS, or DHL.

FAQ

• Q:How do I pick the correct drive?
  A:Match motor horsepower and current to the drive ratings.
• Q:Can I switch networks later?
  A:Use the configured network and route control through your PLC.
• Q:How does overload work?
  A:The Class 10 profile protects the motor during heavy load changes.
• Q:How long does ride-through last?
  A:Most units maintain control for short line drops up to two seconds.
• Q:Where can I get setup help?
  A:Contact our support team or your local distributor for guidance.

Manufacturer Info

• Made by Allen-Bradley, part of the ArmorStart LT distributed motor control line.
• Model 294D-FD4P2Z-G2-3 supports on-machine motor starting and speed control.
