Allen-Bradley 25B-E9P9N104 PowerFlex 525 Drive | 7.5HP 600V

Allen-Bradley 25B-E9P9N104 PowerFlex 525 AC Drive – Premium Motor Control Solution

Download the full product manual: PowerFlex 520 Series Technical Documentation

Technical Specifications

• Brand: Allen-Bradley/Rockwell Automation
• Model: 25B-E9P9N104
• Series: PowerFlex 525
• Input: 525-600V AC 3-phase
• Output: 0-575V AC, 9.9A
• Frequency Range: 0-500Hz
• Control Accuracy: ±0.1% base speed
• Efficiency: 97.5%

Installation & Operation

• Frame Size: C
• Enclosure: IP20/NEMA Open
• Dimensions: 109 x 220 x 184mm
• Weight: 2.3kg
• Temperature Range: -4°F to 122°F

Advanced Control Features

• 4 programmable acceleration/deceleration times
• Multiple stop modes (ramp, coast, DC-brake)
• 7 digital inputs (24V DC)
• 2 analog inputs (0-10V DC/4-20mA)
• 2 programmable relay outputs

Certifications & Support

• Certifications: c-UL-us, ATEX, CE, TUV, KCC, RoHS
• Warranty: 12 months
• Shipping: FedEx, UPS, DHL worldwide

Frequently Asked Questions

• Q: What’s the difference between normal and heavy duty ratings?
  A: Both are 7.5HP/5.5kW in this model.
• Q: Does it include EMC filtering?
  A: No, this model has no EMC filter.
• Q: What communication protocols are supported?
  A: Ethernet/IP is built-in.
• Q: What overload protection is included?
  A: Class 10 protection with I²T algorithm.
• Q: Is the display backlit?
  A: Yes, the LCD has clear visibility.
