Allen Bradley PowerFlex 70 Drive – Premium Motor Control Solution
The 20AD5P0A0AYNNNC0 PowerFlex 70 drive delivers reliable 3 HP motor control with enhanced features for industrial applications. This 480V AC drive offers robust performance in a compact frame B design.
Drive Configuration Details
- Complete Model: 20AD5P0A0AYNNNC0
- Voltage Rating: 480V AC three-phase power
- Current Capacity: 5 Amps continuous output
- Power Rating: 3 HP normal duty operation
- Enclosure Type: Panel mount IP20/NEMA Type 1
- Control Type: Enhanced control board
- Brake Feature: IGBT brake installed
- Interface: Blank plate cover included
Performance Specifications
- Manufacturer: Allen Bradley
- Product Line: PowerFlex 70
- Output Current: 5A continuous, 7.5A for 3 seconds
- Power Capacity: 2.2 kW (3.0 HP) normal duty
- Heavy Duty Rating: 2 HP maximum capacity
- Frame Size: Compact B frame design
- Weight: 8.81 lbs (4.00 kg) lightweight
- Protection: Conformal coating applied
- Safety Rating: DriveGuard Safe-Off compatible
- Cooling: External fan capability
- Communication: No network module installed
Package Contents
- PowerFlex 70 main drive unit
- Blank cover plate for interface
- Service connection board
- Front cover with PowerFlex 70 logo
- Conduit plate for mounting
- External fan for heat sink cooling
- 115VAC digital interface board
- DriveGuard Safe-Off option board
Shipping & Warranty Protection
- 12-month comprehensive warranty
- Express shipping via FedEx, UPS, DHL
- Professional packaging protection
- Fast order processing service
- Global shipping availability
- Author: Powergear X Automation
Technical Application Questions
- What applications suit this PowerFlex 70 model?
This drive works well for pumps, fans, conveyors and other 3 HP motor applications requiring precise speed control.
- Can I add communication modules later?
Yes, the drive supports optional communication modules for network integration when needed.
- What does enhanced control provide?
Enhanced control offers better performance and more features than standard versions.
- How does the brake IGBT function help?
The installed brake IGBT allows quick motor stopping when used with an external resistor.
- What maintenance does this drive require?
Regular cleaning, proper ventilation, and periodic component checks ensure long service life.
Contact our team at sales@powergearx.com or +86 18030005825 for expert advice on the Allen Bradley 20AD5P0A0AYNNNC0 drive.
