Allen-Bradley 1769-PA4 CompactLogix AC Power Supply

Allen-Bradley 1769-PA4: CompactLogix AC Power Supply

The Allen-Bradley 1769-PA4 is a robust AC power supply module from Rockwell Automation. It delivers reliable backplane power for CompactLogix 1769-L3x controllers and I/O modules. This unit supports a wide input voltage range and powers large system configurations.

Complete Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1769-PA4
• Input Voltage: 85–265V AC or 170–265V AC (switch-selectable)
• Nominal Input: 120/220V AC
• Input Frequency: 47–63 Hz
• Output Current: 4.0A @ 5V DC; 2.0A @ 24V DC
• Power Consumption: 200 VA @ 120V AC; 240 VA @ 240V AC
• Inrush Current: 25A maximum @ 132V AC
• Fuse Type: Littelfuse 02153.15MXP or Wickmann 19195-3.15A
• Operating Temperature: 0 to 60°C (32 to 140°F)
• Weight: 525 g (1.16 lb)
• Dimensions (HxWxD): 118 x 70 x 87 mm

Package Contents & Shipping

• You will receive one (1) Allen-Bradley 1769-PA4 power supply unit.
• We ship all orders globally via trusted carriers: FedEx, UPS, and DHL.

Frequently Asked Questions

• Q: How many modules can the 1769-PA4 power?
  A: It supports a maximum of 16 I/O modules, with 8 on its left and 8 on its right.
• Q: What fuse does it use for replacement?
  A: Use a Littelfuse 02153.15MXP or a Wickmann 19195-3.15A fuse.
• Q: Is the 1769-PA4 compatible with all CompactLogix controllers?
  A: Yes, it is designed to work with the 1769-L3x series controllers and I/O modules.
