Allen-Bradley 1769-OW16 CompactLogix Relay Output Module

Introduction to the Allen-Bradley 1769-OW16 Relay Output Module

The Allen-Bradley 1769-OW16 is a high-performance relay output module designed for industrial automation. It offers sixteen isolated relay channels, supporting both AC and DC voltage operations. This module ensures reliable control for various applications, from machinery to process systems. Engineers trust the 1769-OW16 for its durability and flexibility in demanding environments.

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1769-OW16 (Series A and B)
• Output Type: 16 Normally Open Relay Channels
• Operating Voltage: 5-265V AC / 5-125V DC
• Max Current per Point: 2.5A
• Max Current per Module: 20A
• On/Off Delay: 10 ms
• Isolation: 1836V AC for 1 second (group-to-bus)
• Operating Temperature: 0 to 60°C
• Wire Compatibility: 22-14 AWG solid or 22-16 AWG stranded
• Power Consumption: 4.75W max dissipation
• Communication: Integrates via CompactLogix or MicroLogix bus

Packaging and Shipping

• Each package includes one 1769-OW16 module and mounting hardware.
• We ship globally via FedEx, UPS, or DHL for fast delivery.
• The module weighs 2 pounds with dimensions of 8x8x5 inches.

Frequently Asked Questions

• What controllers work with the 1769-OW16?
  It connects to MicroLogix 1500 and CompactLogix systems.
• Can I use this module with both AC and DC voltages?
  Yes, it supports mixed voltage applications per group.
• What is the maximum load per channel?
  Each output supports up to 2.5A continuous current.
• How do I configure the module?
  Set parameters like inhibition and diagnostics via controller software.
