Allen-Bradley 1769-L30ERM CompactLogix Controller | Ethernet PLC

Allen-Bradley 1769-L30ERM: CompactLogix Ethernet Controller

The 1769-L30ERM brings powerful control in a compact package. This advanced controller offers dual Ethernet ports and motion control. It works with up to eight I/O modules for flexible automation solutions. The 1769-L30ERM delivers reliable performance for various industrial applications.

Technical Specifications

• Manufacturer: Allen-Bradley/Rockwell Automation
• Model Number: 1769-L30ERM Series A/B
• Memory: 1MB user + 1GB non-volatile (1784-SD1 card included)
• Communication Ports: 2x Ethernet/IP, 1x USB
• Motion Control: 4 axes CIP motion with kinematics
• I/O Capacity: 8 local modules across 3 expansion banks
• Power Consumption: 4.5W maximum dissipation
• Current Draw: 500mA @ 5V DC, 225mA @ 24V DC
• Programming: Studio 5000 Logix Designer (v21+)
• Operating Temperature: 0° to 60°C (32° to 140°F)

Frequently Asked Questions

• Q: What memory card comes with the controller?
  A: It includes a 1784-SD1 card with 1GB storage.
• Q: How many motion axes can it control?
  A: It supports control of up to 4 motion axes.
• Q: What network topologies does it support?
  A: It works with linear, ring, and star topologies.
• Q: What software is needed for programming?
  A: Use Studio 5000 Logix Designer version 21 or later.
• Q: How many I/O modules can be connected?
  A: It supports up to 8 local I/O modules.
