Allen-Bradley 1768-ENBT Ethernet Communication Module

Allen-Bradley 1768-ENBT Ethernet Communication Module

The 1768-ENBT helps your CompactLogix system talk to devices on an Ethernet/IP network. It offers fast and reliable data exchange for industrial automation.

Technical Specifications

• Brand & Manufacturer: Allen-Bradley
• Model Number: 1768-ENBT
• Product Series: CompactLogix 1768
• Ethernet Port: 1 port, RJ45 connector
• Max Connections: 64 CIP / 32 TCP/IP
• Compatible Controllers: 1768-L43 and 1768-L45
• Operating Temperature: 0° to 60°C (32° to 140°F)
• Power Consumption: 4.34 Watts
• Vibration Resistance: 5g (10-500 Hz)
• Shock Resistance: 30g operating shock

Package Contents

• One Allen-Bradley 1768-ENBT communication module
• Quick start installation guide

Shipping Info

• We ship via FedEx, UPS, and DHL
• Shipping weight: 2 pounds
• Package size: 8 x 8 x 5 inches

FAQ

• How many 1768-ENBT modules can I use?
• You can use two with a 1768-L43 controller and four with a 1768-L45.
• What cables does this module require?
• Use standard Cat5 or Cat6 Ethernet cables with RJ45 connectors.
• Can it connect to non-Allen-Bradley devices?
• Yes, it works with many third-party devices using Ethernet/IP.
• What do the status indicators show?
• They show network connection, module health, and link activity.
• Is the module easy to install?
• Yes, it fits into one slot in the 1768 CompactLogix rack.
