Allen-Bradley 1766-L32AWA – Ethernet Programmable Logic Controller

Allen-Bradley 1766-L32AWA: Advanced MicroLogix 1400 Controller

The 1766-L32AWA delivers powerful control with excellent connectivity. This feature-rich PLC combines robust I/O with multiple communication options. It offers superior performance for industrial automation applications.

Technical Specifications

• Brand: Allen-Bradley
• Model: 1766-L32AWA (MicroLogix 1400 Series)
• Input Power: 120-240V AC (47-63 Hz)
• Digital Inputs: 20 × 120V AC
• Digital Outputs: 12 × Relay
• Relay Rating: 2A @ 240VAC / 1A @ 125VDC
• Communication Ports: 3 total (Ethernet + 2 serial)
• Ethernet Protocol: Ethernet/IP, MODBUS TCP/IP
• Serial Protocols: DF1, ASCII, MODBUS RTU, DNP3
• Memory Capacity: 20 KB user program
• Special Features: Built-in RTC, web server, email
• Expansion Capability: Up to 7 expansion modules
• Operating Temperature: 0°C to 55°C (32°F to 131°F)
• Dimensions: 90 × 180 × 87 mm (3.5 × 7.1 × 3.4 in)
• Weight: 2 lbs (0.9 kg)
• Display: Integrated LCD screen

Package Contents

• One 1766-L32AWA Controller Unit
• Comprehensive Installation Manual
• DIN Rail Mounting Kit
• Debris Protection Strip
• 1-Year Warranty
• Global Shipping: FedEx, UPS, DHL Available

Frequently Asked Questions

• How many expansion modules can this controller support?
  The controller supports up to seven 1762 expansion I/O modules.
• What communication protocols are available on the Ethernet port?
  The Ethernet port supports Ethernet/IP, MODBUS TCP/IP, and DNP3 protocols.
• Does this controller have built-in diagnostics capabilities?
  Yes, it features web server functionality for remote diagnostics.
• Can I use this controller for time-based automation tasks?
  Yes, the built-in real-time clock enables time-stamped operations.
• What is the maximum load for each relay output?
  Each relay output handles up to 2A at 240VAC or 1A at 125VDC.
