Allen-Bradley 1763-MM1 Memory Module for MicroLogix 1100 PLCs

Allen-Bradley 1763-MM1 Memory Module

The Allen-Bradley 1763-MM1 adds 128KB of non-volatile memory to MicroLogix 1100 controllers. This module stores programs and recipes safely. It also moves data between PLCs without losing information.

Technical Specifications

• Brand: Allen-Bradley / Rockwell Automation
• Model: 1763-MM1
• Memory Size: 128 KB
• Memory Type: Non-Volatile
• Compatibility: MicroLogix 1100 Series Controllers
• Data Logging: Not Supported
• Recipe Logging: Supported
• Program Compare: Supported
• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Compliance: EMC, LVD, RoHS
• Product Status: End of Life (Discontinued April 2022)

Packaging List

• One Allen-Bradley 1763-MM1 Memory Module
• Basic installation instructions
• We ship via FedEx, UPS, or DHL for quick delivery

Frequently Asked Questions

• Can I use the 1763-MM1 to expand my controller’s memory?
  No. This module does not increase the controller’s built-in memory. It provides separate storage.
• How do I transfer a program using this memory module?
  Save your program to the module. Then insert it into another MicroLogix 1100 and load the program.
• Is the stored data safe during power loss?
  Yes. The non-volatile memory keeps data safe without any power source.
• What replaces the 1763-MM1 since it is discontinued?
  Rockwell Automation suggests using the Micro 800 series as a modern replacement.
• Can I leave the memory module in the controller during operation?
  Yes. You can install it permanently for automatic program loading on startup.
