Allen-Bradley 1763-L16DWD: Compact MicroLogix 1100 Controller with Display
The 1763-L16DWD from Allen-Bradley (Rockwell Automation) is a versatile MicroLogix 1100 series controller. It combines digital and analog I/O with built-in Ethernet and a display for complete control in a compact package. This DC-powered unit is perfect for small to medium automation applications.
Complete Technical Specifications
- Brand & Manufacturer: Allen-Bradley (Rockwell Automation)
- Full Model Number: 1763-L16DWD
- Input Power: 12-24V DC
- Digital Inputs: 10 points (24V DC sink/source)
- High-Speed Inputs: 4 points (channels 0-3)
- Analog Inputs: 2 channels (0-10V DC)
- Analog Resolution: 10-bit unsigned integer
- Outputs: 6 relay outputs (10A @ 120/240V AC, 10A @ 24/125V DC)
- Communication Ports: Ethernet, RS-232/485 combo
- Protocols: DF1, DH485, MODBUS, ASCII, Ethernet/IP
- Display: Integrated LCD with keypad
- Operating Temperature: -20°C to 65°C (-4°F to 149°F)
- Shock Rating: 30G in 3 directions
- Vibration Rating: 1.5G maximum
- Dimensions: 3.5 x 4.33 x 3.43 inches
- Weight: 2.0 pounds
Packaging & Shipping
- One (1) Allen-Bradley 1763-L16DWD controller unit
- One (1) Set of installation and user documentation
- This product ships via FedEx, UPS, or DHL worldwide
Frequently Asked Questions (FAQ)
- What types of analog signals can the inputs handle?
The analog inputs accept 0-10V DC signals and work with 2, 3, and 4-wire transmitters. - Can I use this controller in hazardous locations?
Yes, it is certified for Class 1, Division 2, Groups A, B, C, and D hazardous locations. - What is the purpose of the high-speed inputs?
The four high-speed inputs are ideal for applications requiring fast response times like counting or timing. - Does the controller have memory backup?
Yes, it includes a backup battery for volatile memory (RAM) protection. - Can I connect HMI devices to this controller?
Yes, you can connect HMIs through either the Ethernet port or serial communication ports.
