Allen-Bradley 1763-L16BBB – Ethernet Programmable Logic Controller

Allen-Bradley 1763-L16BBB: Compact MicroLogix 1100 Controller

The 1763-L16BBB delivers powerful control in a compact package. This versatile PLC combines digital and analog I/O with Ethernet connectivity. It offers excellent performance for small automation applications.

Technical Specifications

• Brand: Allen-Bradley
• Model: 1763-L16BBB (MicroLogix 1100 Series)
• Input Power: 24VDC (-15% to +10%)
• Digital Inputs: 12 × 24VDC (4 high-speed @ 20kHz)
• Analog Inputs: 2 × 0-10VDC (10-bit resolution)
• Digital Outputs: 2 relay + 4 FET
• Relay Rating: 2.5A @ 240VAC / 1.0A @ 125VDC
• FET Rating: 24VDC continuous operation
• Communication: RS-232/485 + Ethernet (10/100 Mbps)
• Protocols: DF1, MODBUS, Ethernet/IP
• Display: Built-in LCD for data monitoring
• Operating Temperature: -20°C to 65°C (-4°F to 149°F)
• Shock Resistance: 30G operational rating
• Hazardous Location: Class 1 Div 2 Certified
• Dimensions: 3.5″ × 4.33″ × 3.43″
• Weight: 1.8 lbs (0.8 kg)

Package Contents

• One 1763-L16BBB Controller Unit
• Installation and Programming Manual
• Mounting Hardware Kit
• 1-Year Warranty
• Worldwide Shipping: FedEx, UPS, DHL Available

Frequently Asked Questions

• What communication protocols does this controller support?
  It supports DF1, MODBUS, and Ethernet/IP protocols for flexible connectivity.
• Can I use this controller in hazardous locations?
  Yes, it carries Class 1 Division 2 certification for hazardous areas.
• What is the maximum switching frequency for high-speed inputs?
  The four high-speed inputs support up to 20kHz switching frequency.
• Does this controller have analog inputs?
  Yes, it features two 0-10VDC analog inputs with 10-bit resolution.
• What is the advantage of having both relay and FET outputs?
  Mixed outputs allow handling both AC/DC loads and fast switching applications.
