Allen-Bradley 1763-L16AWA PLC Controller | MicroLogix 1100 Series

Allen-Bradley 1763-L16AWA: Compact Programmable Controller

The 1763-L16AWA is a powerful MicroLogix 1100 controller from Allen-Bradley. It combines digital and analog I/O with built-in communication ports. This all-in-one unit is perfect for small to medium automation projects.

Key Technical Specifications

• Input Power: 120-240V AC
• Digital Inputs: 12 points @ 120V AC
• Analog Inputs: 2 channels @ 0-10V DC
• Outputs: 6 relay points @ 10A each
• Resolution: 10-bit for analog signals
• Communication: Ethernet & RS-232/485 ports
• Display: Integrated LCD screen
• Operating Temp: 0° to 55°C (32° to 131°F)

Package Includes

• One Allen-Bradley 1763-L16AWA controller unit
• Required mounting hardware and documentation

Shipping & Warranty Details

• Fast worldwide shipping via FedEx, UPS, and DHL
• Full 12-month warranty included
• Professional technical support available

Frequently Asked Questions

What communication protocols does it support?

• The controller supports EtherNet/IP for modern networks. It also works with DF1 and Modbus protocols through its serial port.

Can I expand the I/O capacity of this controller?

• Yes. You can add up to 4 expansion modules for more inputs and outputs. This lets you customize the system for your needs.

How do I program this MicroLogix controller?

• You use Rockwell’s RSLogix 500 software. The Ethernet port makes programming and monitoring very easy from your computer.

What is the lifetime of the relay outputs?

• The relay contacts last for 10 million mechanical operations. For electrical operations, it depends on the load type and current.

Is the analog input configurable for different ranges?

• The analog input is fixed at 0-10V DC range. You can scale these values in the program for your specific application needs.
