Allen-Bradley 1762-L40BWA MicroLogix 1200 40 I/O

Allen-Bradley 1762-L40BWA MicroLogix 1200 Controller

The Allen-Bradley 1762-L40BWA offers strong performance in automation. This MicroLogix 1200 controller handles up to 40 I/O points for flexible use.

⚙️ Technical Specifications

• Brand: Allen-Bradley
• Model: 1762-L40BWA
• Input Power: 120–240V AC, 47–63 Hz
• Inputs: 24 x 24V DC (20 standard + 4 high-speed)
• Outputs: 16 Relay
• Relay Rating: 2A @ 240V AC / 2A @ 125V DC
• Mechanical Life: 20,000,000 cycles
• Operating Temp: 0° to 55°C
• Dimensions: 90mm H x 160mm W x 87mm D
• Weight: 2.4 pounds

📦 Packaging List

• 1762-L40BWA Controller Unit
• Quick Start Guide
• DIN Rail Clip (pre-installed)
• Shipping Carrier: FedEx, UPS, or DHL

❓ Frequently Asked Questions

• What communication protocols does the 1762-L40BWA support?
  It supports DF1, DH-485, Modbus RTU, and ASCII protocols.
• Can the relay outputs switch DC loads?
  Yes, the relays can handle both AC and DC loads.
• What is the maximum load current per relay?
  Each relay can switch up to 2A at 125V DC or 240V AC.
• Is the unit rated for use in harsh environments?
  It operates reliably in temperatures from 0° to 55°C.
• Does the controller include a power supply?
  Yes, it has an internal power supply for the inputs and logic.

All our products come with a 12-month warranty. We ship via FedEx, UPS, or DHL.
