Allen-Bradley 1762-L24BWA – Compact Relay Output PLC Module

Introducing the Allen-Bradley 1762-L24BWA MicroLogix 1200 Controller

The Allen‑Bradley 1762-L24BWA delivers high performance in a compact design. This PLC offers flexible connectivity and reliable operation for small-scale automation applications. It combines digital inputs and relay outputs in one efficient unit.

Technical Specifications

• Brand: Allen-Bradley
• Model: 1762-L24BWA (MicroLogix 1200 Series)
• Input Power: 24VDC
• Input Channels: 14 (10 standard + 4 high-speed)
• Output Type: 10 Relay Outputs
• Contact Rating: 24-125VDC; 120-240VAC
• Mechanical Life: 20,000,000 cycles
• Operating Temperature: 0 to 55°C
• Communication: RS232 (DH485, DF1, Modbus, ASCII)
• Mounting: DIN Rail or Panel
• Dimensions: 90H x 110W x 87D mm
• Weight: 2 lbs
• Shipping: FedEx, UPS, DHL

Packaging List

• One 1762-L24BWA MicroLogix 1200 Controller Unit
• Quick Start Guide
• DIN Rail Mounting Clip (if applicable)

Frequently Asked Questions

• What communication protocols does the 1762-L24BWA support?
  It supports DH485, DF1, Modbus RTU, and ASCII protocols.
• Can this controller work with other Allen-Bradley expansion modules?
  Yes, it easily integrates with MicroLogix expansion I/O.
• What is the maximum load per relay output?
  Each relay can handle up to 10A at 240VAC or 125VDC.
